Harmonic Measurement Data (3P3W+1P3W)
Content
V
U2(n)_INST(V)_3P nth order harmonic voltage 2 rms value
U1(n)_INST(V)_3P nth order harmonic voltage 1 rms value
U3(n)_INST(V)_3P nth order harmonic voltage 3 rms value
A
W
I2(n)_INST(A)_3P nth order harmonic current 2 rms value
I1(n)_INST(A)_3P nth order harmonic current 1 rms value
I3(n)_INST(A)_3P nth order harmonic current 3 rms value
V
U1(n)_INST(V)_1P nth order harmonic voltage 1 rms value
U2(n)_INST(V)_1P nth order harmonic voltage 2 rms value
A
I1(n)_INST(A)_1P nth order harmonic current 1 rms value
%
deg
U1cont(n)_INST(%)_3P nth order harmonic voltage 1 content
U2cont(n)_INST(%)_3P nth order harmonic voltage 2 content
U3cont(n)_INST(%)_3P nth order harmonic voltage 3 content
I1cont(n)_INST(%)_3P nth order harmonic current 1 content
I2cont(n)_INST(%)_3P nth order harmonic current 2 content
I3cont(n)_INST(%)_3P nth order harmonic current 3 content
Pcont(n)_INST(%)_3P nth order harmonic electric power content
U1cont(n)_INST(%)_1P nth order harmonic voltage 1 content
U2cont(n)_INST(%)_1P nth order harmonic voltage 2 content
I1cont(n)_INST(%)_1P nth order harmonic current 1 content
I2cont(n)_INST(%)_1P nth order harmonic current 2 content
U1pa(n)_INST(deg)_3P nth order harmonic voltage 1 phase angle
U2pa(n)_INST(deg)_3P nth order harmonic voltage 2 phase angle
U3pa(n)_INST(deg)_3P nth order harmonic voltage 3 phase angle
I1pa(n)_INST(deg)_3P nth order harmonic current 1 phase angle
I2pa(n)_INST(deg)_3P nth order harmonic current 2 phase angle
I3pa(n)_INST(deg)_3P nth order harmonic current 3 phase angle
Ppa(n)_INST(deg)_3P nth order harmonic electric power phase angle
U1pa(n)_INST(deg)_1P nth order harmonic voltage 1 phase angle
U2pa(n)_INST(deg)_1P nth order harmonic voltage 2 phase angle
I1pa(n)_INST(deg)_1P nth order harmonic current 1 phase angle
I2pa(n)_INST(deg)_1P nth order harmonic current 2 phase angle
Ppa(n)_INST(deg)_1P nth order harmonic electric power phase angle
Pcont(n)_INST(%)_1P nth order harmonic electric power content
I2(n)_INST(A)_1P nth order harmonic current 2 rms value
P(n)_INST(W)_3P nth order harmonic electric power value
W
P(n)_INST(W)_1P nth order harmonic electric power value
• Harmonic order 01 to 50 is entered for n.
• For the average value, INST becomes AVE.
• For the maximum value, INST becomes MAX.
• For the minimum value, INST becomes MIN.
