YOKOGAWA F3CU04-1S User Manual

A2-3
IM 34M06H62-02E 3rd Edition : Jul.16
,
2015-00
Table A2.4 Instrument Range and Accuracy (for high resolution operation with SW1-1 set to OFF) 1/4
Input
Category
Input
Type
*1
Instrument Range
*2
Input Type Selector Switch
*3
Software Setting Accuracy
*4
Resolution
*2
SW1-3 SW1-4 SW5
Software setting (factory setting) OFF OFF 0
Instrument ranges
may be specified by software using one of the
following codes.
Thermocouple
K
*5
-200.0 to 1370.0C
OFF OFF
1 1 ($01)
 0.5C
*5
0.1C
*5
-200.0 to 1000.0C 2 2 ($02)
-200.0 to 500.0C 3 3 ($03)

0.5C
*
6
0.1C
*
6
J
-200.0 to 1200.0C 4 4 ($04)

0.5C
*
7
0.1C
*
7
-200.0 to 500.0C 5 5 ($05)

0.5C
*
8
0.1C
*
8
T -270.0 to 400.0C 6 6 ($06)

0.5C
*
9
0.1C
*
9
B
*
10
0.0 to 1600.0C 7 7 ($07)

1.0C
*
10
0.1C
*
10
S
*
11
0.0 to 1600.0C 8 8 ($08)

1.0C
*
11
0.1C
*
11
R
*
11
0.0 to 1600.0C 9 9 ($09)

1.0C
*
11
0.1C
*
11
N -200.0 to 1300.0C A 10 ($0A)

0.6C
*
12
0.1C
*
12
E -270.0 to 1000.0C B 11 ($0B)

0.5C
*
13
0.1C
*
13
L -200.0 to 900.0C C 12 ($0C)

0.6C 0.1C
U -200.0 to 400.0C D 13 ($0D)

0.6C 0.1C
W
*1
4
0.0 to 1600.0C E 14 ($0E)

0.8C
14
0.1C
14
Platinel 2 0.0 to 1390.0C F 15 ($0F)

0.6C 0.1C
RTD
JPt100
-200.0 to 500.0C
OFF ON
0 16 ($10)
 0.4C 0.1C
-200.0 to 200.0C 1 17 ($11)
0.0 to 300.0C 2 18 ($12)

0.3C 0.1C
0.00 to 150.00C 3 19 ($13)

0.20C 0.03C
Pt100
-200.0 to 850.0C 4
20 ($14)

0.4C 0.1C
-200.0 to 500.0C 5 21 ($15)
 0.4C 0.1C
-200.0 to 200.0C 6 22 ($16)
0.0 to 300.0C 7 23 ($17)

0.3C 0.1C
0.00 to 150.00C 8 24 ($18)

0.20C 0.03C
DC voltage
DC mV
input
*15
0 to 10.00 mV DC

*16
ON
9 25 ($19)

0.1% of instrument range
 1 digit
*15
0 to 100.0 mV DC A 26 ($1A)
DC V
input
*15
0.000 to 1.000 V DC B 27 ($1B)
0.000 to 5.000 V DC D 29 ($1D)
1.000 to 5.000 V DC E 30 ($1E)
0.00 to 10.00 V DC F 31 ($1F)
*1: Applicable standard is JIS/IEC/DIN (ITS-90) for thermocouples and RTD.
*2: For thermocouples K, B, S, R, and W, input ranges may be set wider than their instrument range (see the notes below). However, if the
input range width exceeds 1600C, the resolution becomes twice the indicated value. Furthermore, the actual range for an acceptable
input is the input range5%.
*3: When you turn on the power after changing the hardware switch settings, data stored in the EEPROM is initialized to follow the switch
settings.
*4: This accuracy applies if the ambient temperature is 25  5C and the input value is within the instrument range. If the input type is
thermocouple and reference junction compensation is used, you should also take into consideration the accuracy of the reference
junction compensation.
*5: For K-type thermocouples, the input range may be set from -270.0 to 1370.0C beyond its instrument range. The accuracy and
resolution depend on measured temperatures as follows:
-270.0 to -200.0C: Neither accuracy or resolution is guaranteed.
-200.0 to 0.0C: 1.0C accuracy, 0.2C resolution
*6: For K-type thermocouples, the accuracy and resolution depend on measured temperatures as follows:
-200.0 to -180.0C: 0.9C accuracy, 0.2C resolution
-180.0 to -100.0C: 0.6C accuracy, 0.1C resolution
*7: For J-type thermocouples, the accuracy and resolution depend on measured temperatures as follows:
-200.0 to -100.0C: 1.0C accuracy, 0.2C resolution
*8: For J-type thermocouples, the accuracy and resolution depend on measured temperatures as follows:
-200.0 to -150.0C: 0.6C accuracy, 0.1C resolution
*9: For T-type thermocouples, the accuracy and resolution depend on measured temperatures as follows:
-270.0 to -200.0C: 3.5C accuracy, 0.5C resolution
-200.0 to -100.0C: 1.0C accuracy, 0.1C resolution
*10: For B-type thermocouples, the input range may be set from 0.0 to 1800.0C beyond its instrument range. The accuracy and resolution
depend on measured temperatures as follows:
0.0 to 300.0C: Neither accuracy nor resolution is guaranteed.
300.0 to 900.0C: 2.5C accuracy, 0.3C resolution
*11: For S-type and R-type thermocouples, the input range may be set from 0.0 to 1700.0C beyond its instrument range. The accuracy and
resolution depend on measured temperatures as follows:
0.0 to 200.0C: 1.5C accuracy, 0.2C resolution
*12: For N-type thermocouples, the accuracy and resolution depend on measured temperatures as follows:
-200.0 to 0.0C: 1.3C accuracy, 0.3C resolution
*13: For E-type thermocouples, the accuracy and resolution depend on measured temperatures as follows:
-270.0 to -200.0C: 6.5C accuracy, 2.0C resolution
-200.0 to -100.0C: 1.0C accuracy, 0.2C resolution
*14: For W-type thermocouples, the input range may be set from 0.0 to 2300.0C beyond its instrument range. The accuracy and resolution
depend on measured temperatures as follows:
0.0 to 100.0C: 1.0C accuracy, 0.2C resolution
*15: Resolution is determined by the upper and lower limits for the input range, as well as the upper and lower scaling limits. It is represented
by one digit.
*16: "" means that the value is ignored.
