Commands and Responses
1
2
App
SRecDisp
Channel for Recording Display Data
Sets the channel for recording display data.
Syntax
SRecDisp,p1,p2,p3
p1
Number (see “Description”)
p2
Channel type
Off
Do not record display data.
IO
I/O channel
Math
Math channel
Com
Communication channel
p3
Channel number
Query
SRecDisp[,p1]?
Example Assign the display data of I/O channel 0005 to
number 10 and record.
SRecDisp,10,IO,0005
Description
• You cannot use this command to configure settings
while recording is in progress.
• You cannot use this command to configure settings
while computation is in progress.
• You cannot use this command to configure settings
when the measurement mode is set to dual interval.
• If p2=Off, you cannot set p3.
• There is a limit to the number of recording channels
depending on the recording interval (SDispData
command).
Recording
Interval
Number of Recording Channels
5 s/div 100
10 s/div 200
15 s/div or higher 500
For the large memory type (GX20-2/GP20-2/GM10-2),
the following table applies.
Recording
Interval
Number of Recording Channels
When recording only
display data
When recording display
data and event data
5s/div 200 100
10s/div 500 200
15s/div 1000 500
30s/div or
more
1000 1000
• You cannot set a channel more than once.
SRecEvent
Channel for Recording Event Data
Sets the channel for recording event data.
Syntax
SRecEvent,p1,p2,p3,p4
p1
Scan group (1 or 2)
p2
Number (see “Description”)
p3
Channel type
Off
Do not record event data.
IO
I/O channel
Math
Math channel
Com
Communication channel
p4
Channel number
Query
SRecEvent[,p1[,p2]]?
Example Assign the event data of I/O channel 0006 to
number 11 and record.
SEventData,1,11,IO,0006
Description
• You cannot use this command to configure settings
while recording is in progress.
• You cannot use this command to configure settings
while computation is in progress.
• If p3=Off, you cannot set p4.
• This setting is valid when event data recording is
enabled (recording mode of the SMemory command).
• There is a limit to the number of recording channels
depending on the recording interval (SEventData
command).
Recording
Interval
Number of Recording Channels
100 ms 100
200 ms 200
500 ms or more 500
For the large memory type (GX20-2/GP20-2/GM10-2),
the following table applies.
Recording
Interval
Number of Recording Channels
When recording only
event data
When recording display
data and event data
100ms 500 100
200ms 500 200
500ms 1000 500
1s or more 1000 1000
• If the recording interval is 50 ms or less, there are
limits to the number of recording channels depending
on the model and measurement mode.
High speed0
Recording interval
Model 1ms 2ms 5ms 10ms 20ms 50ms
GX/GP10 2ch 4ch 10ch 20ch 40ch 100ch
GX/GP20-1 2ch 4ch 10ch 20ch 40ch 100ch
GX/GP20-2 10ch 20ch 50ch 100ch 150ch 150ch
GM10-1 2ch 4ch 10ch 20ch 40ch 100ch
GM10-2 10ch 20ch 50ch 100ch 150ch 150ch
Dual interval
Recording interval
Model 1ms 2ms 5ms 10ms 20ms 50ms
GX/GP10 - - 5ch 10ch 20ch 50ch
GX/GP20-1 - - 5ch 10ch 20ch 50ch
GX/GP20-2 5ch 10ch 25ch 40ch 50ch 50ch
GM10-1 - - 5ch 10ch 20ch 50ch
GM10-2 5ch 10ch 25ch 40ch 50ch 50ch
• You cannot set a channel more than once.
•
When the measurement mode is set to dual interval and
p3 = IO, you can set the channels of only the applicable
scan groups.
• If the measurement mode is set to dual interval, p3
= Math and p3 = Com can be specified only on scan
groups operating at the master scan interval.
2.4 Setting Commands
