2-23
IM 04L51B01-17EN
Commands and Responses
2
• You cannot use this command to configure settings
while computation is in progress.
• If p2=TC/RTD/DI/OHM, you cannot specify p4=Sqrt.
• If p2=GS, you cannot specify p4=Off/Delta.
• If p2=DI, you cannot set p7.
• If an electro-magnetic relay type or low withstand
voltage relay type analog input module is in use, you
cannot specify p2=RTD.
• For 4-wire RTD modules, p2 cannot be set to Volt, TC,
GS, or DI. (Only SKIP, RTD, and OHM are selectable.)
• p2 = OHM is valid only for 4-wire RTD modules.
• The settable items for p3 are shown below.
p2=Volt p2=TC p2=RTD p2=GS p2=DI
20mV R Pt100 1-5V Level
60mV S Pt100-H 0.4-2V DI
200mV B JPt100
1V K JPt100-H
2V K-H Cu10GE
6V E Cu10LN
20V J Cu10WEED
50V T Cu10BAILEY
100V
1
N Cu10a392
W Cu10a393
L Cu25
U Cu53
PLATINEL Cu100
PR20-40 J263B
WRe3-25 Ni100SAMA
KpvsAu7Fe Ni100DIN
NiNiMo Ni120
WWRe26 Pt25
N14 Pt50
XK Pt200WEED
Cu10G
Cu50G
Cu100G
Pt46G
Pt100G
Pt500
2
Pt1000
2
1 Valid only for high-speed AI modules
2 Valid only for 4-wire RTD modules
• If p4=LogT1 on a Log scale channel, set the value in
the following range.
• p5<p6
• p9, p10
p9<p10. The maximum span is 15 decades.
If the mantissa of p9 is 1.00, the minimum span is
1 decade.
If the mantissa of p9 is not 1.00, the minimum
span is 2 decades.
• If p4=LogT2 or LogT3 on a Log scale channel, set the
value in the following range.
• p5<p6
• p9, p10
The maximum span is 15 decades; the minimum
is 1 decade.
If the mantissa of p9 is not 1.00, the exponent
is +14 or less, and the maximum span is 14
decades.
SRangeAICurrent
Measurement Range of Current Input
Type AI Channel
Sets the measurement range of an current input type AI
channel.
Unused Channels
Syntax
SRangeAICurrent,p1,p2
p1
Channel number
p2
Input type (Skip)
Channels Whose Input Type is Current and No Math
Syntax
SRangeAICurrent,p1,p2,p3,p4,p5,p6
,p7
p1
Channel number
p2
Input type (Current)
p3
Range (0-20mA)
p4
Math type (Off)
p5
Span lower limit
p6
Span upper limit
p7
Bias (–999999 to 999999)
Delta Channels
Syntax
SRangeAICurrent,p1,p2,p3,p4,p5,p6,
p7,p8
p1
Channel number
p2
Input type (Current)
p3
Range (0-20mA)
P4
Math type (Delta)
p5
Span lower limit
p6
Span upper limit
p7
Bias (–999999 to 999999)
p8
Reference channel number
Scaling Channels
Syntax
SRangeAICurrent,p1,p2,p3,p4,p5,p6,
p7,p8,p9,p10,p11
p1
Channel number
p2
Input type (Current)
p3
Range (0-20mA)
P4
Math type (Scale)
p5
Span lower limit
p6
Span upper limit
p7
Bias (–999999 to 999999)
p8
Decimal place (0 to 5)
p9
Scaling lower limit
p10
Scaling upper limit
p11
Unit (up to 6 characters, UTF-8)
Scaling Channels (General Signal 4-20 mA Input)
Syntax
SRangeAICurrent,p1,p2,p3,p4,p5,p6,
p7,p8,p9,p10,p11,p12,p13
p1
Channel number
p2
Input type (GS)
p3
Range (4-20mA)
P4
Math type (Scale)
2.4 Setting Commands
