YOKOGAWA GX10 User Manual

2-24
IM 04L51B01-17EN
p5
Span lower limit
p6
Span upper limit
p7
Bias (–999999 to 999999)
p8
Decimal place (0 to 5)
p9
Scaling lower limit
p10
Scaling upper limit
p11
Unit (up to 6 characters, UTF-8)
p12
Low-cut function (Off, On)
p13
Low-cut point (0 to 50)
Square Root Channels
Syntax
SRangeAICurrent,p1,p2,p3,p4,p5,p6,
p7,p8,p9,p10,p11,p12,p13,p14
p1
Channel number
p2
Input type (Current, GS)
p3
Range
0-20mA
When p2 = Current
4-20mA
When p2 = GS
P4
Math type (Sqrt)
p5
Span lower limit
p6
Span upper limit
p7
Bias (–999999 to 999999)
p8
Decimal place (0 to 5)
p9
Scaling lower limit
p10
Scaling upper limit
p11
Unit (up to 6 characters, UTF-8)
p12
Low-cut function (Off, On)
p13
Low-cut point (0 to 50)
p14
Low-cut output (Zero, Linear)
Query
SRangeAICurrent[,p1]?
Example Measure 0.000 to 10.000 mA on channel 0002.
No scaling. No bias.
SRangeAICurrent,0002,Current,0-
20mA,Off,0,10000,0
Description
• You cannot use this command to configure settings
while recording is in progress.
• You cannot use this command to configure settings
while computation is in progress.
• If p2=GS, you cannot specify p4=Off/Delta.
• Specify p5 and p6 within the range shown in the
following table.
Range (p3) Value (p5, p6)
0-20mA 0.000 to 20.000
4-20mA 3.200 to 20.800
SRangePulse
Measurement Range of Pulse Input
Channel
Sets the measurement range of a pulse input channel.
Unused Channels
Syntax
SRangePulse,p1,p2
p1
Channel number
p2
Input type (Skip)
Channels Whose Input Type is PulseInput and No
Math
Syntax
SRangePulse,p1,p2,p3,p4,p5,p6,p7
p1
Channel number
p2
Input type (PulseInput)
p3
Range (LevelRange, ContactRange)
LevelRange
Level
ContactRange
Contact
p4
Chattering filter (On, Off)
p5
Math type (Off)
p6
Span lower limit
p7
Span upper limit
Channels Whose Input Type is PulseInput and Delta
Syntax
SRangePulse,p1,p2,p3,p4,p5,p6,p7
,p8
p1
Channel number
p2
Input type (PulseInput)
p3
Range (LevelRange, ContactRange)
LevelRange
Level
ContactRange
Contact
p4
Chattering filter (On, Off)
p5
Math type (Delta)
p6
Span lower limit
p7
Span upper limit
p8
Reference channel number
Channels Whose Input Type is PulseInput and Linear
Scaling
Syntax
SRangePulse,p1,p2,p3,p4,p5,p6,p7,p
8,p9,p10,p11
p1
Channel number
p2
Input type (PulseInput)
p3
Range (LevelRange, ContactRange)
LevelRange Level
ContactRange Contact
p4
Chattering filter (On, Off)
p5
Math type (Scale)
p6
Span lower limit
p7
Span upper limit
p8
Decimal place (0, 1, 2, 3, 4, 5)
p9
Scaling lower limit
p10
Scaling upper limit
p11
Unit
Query
SRangePulse[,p1]?
Example Measure the pulse (level) on channel 0002.
Chattering filter is on. Math is on.
SRangePulse,0002,PulseInput,LevelR
ange,On,Off,0,1000,0,200,"m3/min"
Description
• You cannot use this command to configure settings
while recording is in progress.
• You cannot use this command to configure settings
while computation is in progress.
2.4 Setting Commands
