Commands and Responses
1
2
App
SModLimit
Modbus Server Connection Limit
Enables or disables the Modbus server connection limit
function.
Syntax
SModLimit,p1
p1
Connection limit (Off, On)
Query
SModLimit?
Example Enable connection limit.
SModLimit,On
SModList
IP Address to Allow Connection to
Modbus Server
Sets the IP address to allow connection to Modbus server.
Syntax
SModList,p1,p2,p3
p1
Registration number (1 to 10)
p2
Enable or disable registration (Off, On)
p3
IP address (0.0.0.0 to 255.255.255.255)
Query
SModList[,p1]?
Example Register IP address “192.168.111.24” to
registration number 1.
SModList,1,On,192.168.111.24
SWattList
WT Communication Connection Server
(/E2)
Sets the WT communication connection server.
Syntax
SWattList,p1,p2,p3,p4
p1
Registration number
p2
Enable or disable (On, Off)
p3
Server name (up to 64 characters, ASCII)
p4
Model (WT300, WT500, WT1800)
Query
SWattList[,p1]?
Example Register model WT1800 and server name
“Watt01” in registration number 1.
SWattList,1,On,Watt01,WT1800
SWattClient
WT Communication Operation (/E2)
Sets the WT communication operation.
Syntax
SWattClient,p1,p2
p1
Read cycle (500ms, 1s, 2s, 5s, 10s, 20s,
30s)
p2
Recovery wait time (5s, 10s, 30s, 1min,
2min, 5min)
Query
SWattClient?
Example Set the read cycle to 10 seconds and recovery
wait time to 2 minutes.
SWattClient,10,2min
SWattData
WT Data Allocation to Communication
Channel (/E2)
Allocates WT data to a communication channel.
Syntax
SWattData,p1,p2,p3,p4,p5,p6,p7
p1
Allocation No
p2
Enable or disable specification (On, Off)
p3
Communication channel
p4
Server registration number
p5
Data group name (see “Description” and
Appendix 6.)
p6
Data name (see Appendix 6.)
p7
Exponential scaling (-9 to 18), default
value 0
Query
SWattData[,p1]?
Example In allocation number 1, allocate the RMS
voltage of element 1 of the WT1800
assigned to server registration number 2 to
communication channel 003.
SWattData,1,On,003,2,Element1,URMS
Description
• The available data groups (p5) vary depending on the
model.
p5 Description Supported Item
WT1800 WT500 WT300
Off Unspecified Yes Yes Yes
Element1 Element 1 data Yes Yes Yes
Element2 Element 2 data Yes Yes Yes
Element3 Element 3 data Yes Yes Yes
Element4 Element 4 data Yes — —
Element5 Element 5 data Yes — —
Element6 Element 6 data Yes — —
ElemHrm1 Element 1 harmonic
data
Yes Yes Yes
ElemHrm2 Element 2 harmonic
data
Yes Yes Yes
ElemHrm3 Element 3 harmonic
data
Yes Yes Yes
ElemHrm4 Element 4 harmonic
data
Yes — —
ElemHrm5 Element 5 harmonic
data
Yes — —
ElemHrm6 Element 6 harmonic
data
Yes — —
SigmaA First wiring unit data Yes Yes Yes
SigmaB Second wiring unit data Yes — —
SigmaC Third wiring unit data Yes — —
Other Other types of data Yes Yes Yes
DeltaA First wiring unit delta
math data
Yes — —
DeltaB Second wiring unit delta
math data
Yes — —
DeltaC Third wiring unit delta
math data
Yes — —
Delta Delta math data — Yes —
Motor Motor option data Yes — —
Aux Auxiliary input option
data
Yes — —
Phase Phase difference data — Yes —
