Commands and Responses
1
2
App
SSLMPCCmd
SLMP client transmission command (/
E4)
Sets the SLMP client transmission command.
Syntax
SSLMPCCmd,p1,p2,p3,p4,p5,p6,p7,p8,
p9,p10,p11,p12,p13
p1
Command number (GX10/GP10: 1 to 50,
GX20-1/GP20-1: 1 to 100, GX20-2/GP20-
2/GM10-2: 1 to 200)
p2
Type
Off
Disable command
Write
Write a value to a Modbus
register of another device.
Read
Read a value from a Modbus
register of another device.
p3
Connection destination number (1 to 16)
p4
See the device code table.
p5
Request destination network number (0
to 255)
p6
Request destination station number (0 to
255)
p7
Request destination module I/O number
(0 to 65535)
p8
Request destination multidrop station
number (0 to 31)
p9
Data type
BIT Bit String data
INT16 16-bit signed integer
UINT16 16-bit unsigned integer
INT32 32-bit signed integer
UINT32 32-bit unsigned integer
FLOAT 32-bit floating point
p10
Head device number (0 to 16777215)
p11
Channel type
IO I/O channel
Math Math I/O channel (/MT)
Com Communication I/O channel (/
MC)
p12
First channel
p13
Last channel
Query
SSLMPCCmd[,p1]?
Example Register “read the bit data assigned to head
device number 1234 of the internal relay of
the device at connection destination server
number 1” to command number 1.
SSLMPCCmd,1,Read,1,M,1234,0,255,10
23,0,BIT,Com,0001,0001
Device Code Table
Device Device
Code
(p4)
p5 to p8 ,
p10 Notation
Data Type
Special relay SM Hexadecimal BIT
Special register SD Hexadecimal INT16/UINT16/
INT32/UINT32/
FLOAT
Input X Hexadecimal BIT
Output Y Hexadecimal BIT
Continued on next page
Device Device
Code
(p4)
p5 to p8 ,
p10 Notation
Data Type
Internal relay M Hexadecimal BIT
Latch relay L Hexadecimal BIT
Annunciator F Hexadecimal BIT
Edge relay V Hexadecimal BIT
Link relay B Hexadecimal BIT
Data register D Hexadecimal INT16/UINT16/
INT32/UINT32/
FLOAT
Link register W Hexadecimal INT16/UINT16/
INT32/UINT32/
FLOAT
Timer Contact TS Hexadecimal BIT
Coil TC Hexadecimal BIT
Current
value
TN Hexadecimal INT16/UINT16/
INT32/UINT32/
FLOAT
Integration
timer
Contact SS Hexadecimal BIT
Coil SC Hexadecimal BIT
Current
value
SN Hexadecimal INT16/UINT16/
INT32/UINT32/
FLOAT
Counter Contact CS Hexadecimal BIT
Coil CC Hexadecimal BIT
Current
value
CN Hexadecimal INT16/UINT16/
INT32/UINT32/
FLOAT
Special link relay SB Hexadecimal BIT
Special link register SW Hexadecimal INT16/UINT16/
INT32/UINT32/
FLOAT
Direct access input DX Hexadecimal BIT
Direct access output DY Hexadecimal BIT
Index register Z Hexadecimal INT16/UINT16/
INT32/UINT32/
FLOAT
Filter register R Decimal INT16/UINT16/
INT32/UINT32/
FLOAT
ZR Hexadecimal INT16/UINT16/
INT32/UINT32/
FLOAT
SSecurity
Security Function
Sets the security function.
Syntax
SSecurity,p1,p2,p3,p4,p5,p6
p1
Operations on the recorder
(GX/GP: Off, Login, Operate)
(GM: Off)
Off
Disables the security function
Login
Enables the login function
Operate
Enables the function that
prohibits touch screen
operation
p2
Operations via communication (Off, Login)
p3
Auto logout
(GX/GP: Off, 1min, 2min, 5min, 10min)
(GM: Off)
P4
Operation without login
(GX/GP: Off, On)
(GM: Off)
P5
Password retry (Off, 3, 5)
2.4 Setting Commands
