YOKOGAWA GX10 User Manual

2-66
IM 04L51B01-17EN
SMonitor
Monitor Screen Display Information [GX/
GP]
Sets the monitor screen display information.
Syntax
SMonitor,p1,p2
p1
Information type (see the table below)
p2
Status (see the table below)
Information Type Status
p1 Description p2
Digital
Digital value display
Off, On
Scroll
Auto scroll
Off, On
Message
Message display
Stream, List
Trend
All channel/group display
Group, All
Grid
Auxiliary grid
Off, On
Axis
Time axis on historical
trend
1, 2, 3, 4, 5,
6, 7, 8
Value
Digital value display on
historical trend
4Value, Max,
Min
Data
Historical data type
Disp, Event1
DigitalWave
Digital waveform display
Off, On
Alarm
Alarm display
Watch, List
Alarm_Sort
Alarm sort item
Time, Channel,
Level, Type
Alarm_Order
Alarm sort order
Ascending,
Descending
Alarm_Time
Detailed alarm time
Off, On
Message_Sort
Message sort item
Datatime,
WriteTime,
Message,
Group, User
Message_Order
Message sort order
Ascending,
Descending
Memory_Data
Memory data type
Disp, Event1,
Event2
Overview
Overview display
Grouping, All
Multi_No
Multi panel number 1 to 20
Custom_No
Customized display
screen number (/CG)
1 to 30
DigitalPos
Digital display position
Default, Top,
Bottom, Left,
Right
DigitalLabel
Display string display
Off, On
Modbus_M
Modbus master status
display type (/MC)
Overview, List
Modbus_C
Modbus client status
display type (/MC)
Overview, List
Watt
WT communication
status display type (/E2)
Overview, List
Switch
Internal switch/DO status
display
All, 1, 2, 3,
4
SLMP_C
SLMP client status
display type (/E4)
Overview, List
ControlGroup
Control group
Controller,
Faceplate
ControlAlarm_
Sort
Control alarm sort item
Time, Loop,
Level, Type
ControlAlarm_
Order
Control alarm sort order
Ascending,
Descending
ControlAlarm_
Time
Control alarm summary
millisecond display
Off, On
Query
SMonitor[,p1]?
Example Set the trend display to all-channel display.
SMonitor,Trend,All
Description
• Custom_No is an option (/CG).
• Modbus_M and Modbus_C are an option (/MC).
• Watt is an option (/E2).
• When p1 = Switch, p2 = 3 or 4 is valid only for the
GX10/GP10.
SMultiPattern
Multi Panel Division [GX/GP]
Sets the multi panel multi panel pattern.
Syntax
SMultiPattern,p1,p2,p3
p1
Registration number (1 to 20)
p2
Multi panel pattern
Wide2
Split 2 Wide
Tall2
Split 2 Tall
Wide3
Split 3 Wide
Tall3
Split 3 Tall
Split4
Split 4 Even
Even5
Split 5 Even
Odd5
Split 5 Odd
Even6
Split 6 Even
Odd6
Split 6 Odd
p3
Multi panel name (up to 16 characters,
UTF-8)
Query
SMultiPattern[,p1]?
Example Set the panel of registration number 1 to
“Split 2 Wide.” Set the multi panel name to
“Monitor1.”
SMultiPattern,1,Wide2,’Monitor1’
Description
• This command is only valid for the GX20/GP20.
• This command can be used only when the multi batch
function (/BT) is disabled.
