SMltGroup
Display Group
Sets the display group for multi batch.
Syntax
SMltGroup,p1,p2,p3,p4,p5
p1
Batch group number (1 to the number
used)
p2
Display group number
p3
Enable or disable (Off, On)
p4
Group name (up to 16 characters, UTF-8)
p5
Channel character string
• Specify using channel numbers. 4-digit
numbers for I/O channels. Numbers
that start with “A” for math channels
(A015). Numbers that start with “C” for
communication channels (C020). The
maximum number of characters per
channel is 4.
• Use periods to separate channel
numbers (see example).
Query
SMltGroup[,p1[,p2]]?
The channel string is output exactly as it is
specified.
Example Assign channels 0001, 0003, 0005, A001, and
C023 to display group 1 of batch group 3 and
name it “GROUP A.”
SMltGroup,3,1,On,’GROUP A’1.3.5.A1.
C23’
Description
• This command is the same as SGroup when p1=1.
SMltTripLine
Display Group Trip Line
Sets the display group trip line for multi batch.
Syntax
SMltTripLine,p1,p2,p3,p4,p5,p6,p7,
p8,p9
p1
Batch group number (1 to the number
used)
p2
Display group number
p3
Trip line number (1 to 4)
p4
Enable or disable (Off, On)
p5
Display position [%] (1 to 100)
p6
R value of RGB display colors (0 to 255)
p7
G value of RGB display colors (0 to 255)
p8
B value of RGB display colors (0 to 255)
p9
Line width
(GX/GP: Thin, Normal, Thick)
(GM: Normal)
Thin Thin
Normal Normal
Thick Thick
Query
SMltTripLine[,p1[,p2[,p3]]]?
Example Display trip line 1 using a thick line in red at the
80% position of display group 2 of batch group
3.
SMltTripLine,3,2,1,80,255,0,0,Thi
ck
SMltSclBmp [GX/GP]
Scale Bitmap
Sets the display group’s scale bitmap file for multi batch.
Syntax
SMltSclBmp,p1,p2,p3
p1
Batch group number (1 to the number
used)
p2
Display group number
p3
Enable or disable (Off, On)
Query
SMltSclBmp[,p1[,p2]]?
Example Use a bitmap scale image on display group 3
of batch group 2.
SMltSclBmp,2,3,On
Description
• This command is valid for the GX20/GP20.
• This command is the same as SSclBmp when p1=1.
SMltMultiPattern
Multi Panel Pattern
Sets the multi panel pattern for multi batch.
Syntax
SMltMultiPattern,p1,p2,p3,p4
p1
Batch group number (1 to the number
used)
p2
Registration number (1 to 20)
p3
Division pattern
Wide2
Split 2 Wide
Tall2
Split 2 Tall
Wide3
Split 3 Wide
Tall3
Split 3 Tall
Split4
Split 4 Even
Even5
Split 5 Even
Odd5
Split 5 Odd
Even6
Split 6 Even
Odd6
Split 6 Odd
p4
Panel name (up to 16 characters, UTF-8)
Query
SMltMultiPattern[,p1[,p2]]?
Example Set batch group 2. Set the panel of registration
number 1 to “Split 2 Wide.” Set the panel name
to “Monitor1.”
SMltMultiPattern,2,1,Wide2’Monit
or1’
Description
• This command is valid for the GX20/GP20.
• This command is valid when the multi batch function (/
BT) is enabled.
