YOKOGAWA GX10 User Manual

2-74
IM 04L51B01-17EN
SCtrlLoopAction
Loop Control
Sets the loop control.
Syntax
SCtrlLoopAction,p1,p2,p3,p4,p5,p6
p1
Loop number
p2
PID initial value
PIDDef_TEMP
Temperature
PIDDef_PRESS
Pressure flow rate
p3
PID selection
SP_SLCT
Target setpoint
selection
(when the /PG option
is not installed)
SP_SEG_SLCT
Target setpoint
selection/segment
PID method
(when the /PG option
is not installed)
ZON_PV
Zone PID method
(PV input)
ZON_TSP
Zone PID method
(final target setpoint)
ZON_SP
Zone PID method
(target setpoint)
FIX_PID
Fixed local PID
selection (PID
number switching
with event action)
p4
EXPV function
Off
EXPV (RPV) is used.
On
EXPV (RPV) is not
used.
p5
RSP function
Off
RSP is not used.
On
RSP is used.
p6
PID control mode
FollowUp
Standard PID control
mode
Fixed-point
Fixed-point control
mode
Query
SCtrlLoopAction[,p1]?
Example Set the loop number L022 control as follows:
PID initial value: Temperature
PID selection: Zone PID method (PV
input)
EXPV (RPV) function: Off
RSP function: On
PID control mode: Standard PID control
mode
SCtrlLoopAction,L022,PIDDef_
TEMP,ZON_PV,Off,On,FollowUp
Description
• This command is valid when a PID Control Module is
installed.
• The RSP function of the secondary side cannot be set
to On (p5=On) in cascade mode.
• The available options for p3 (PID selection) varies
depending on whether the program control function (/
PG option) is available.
SCtrlSPPID
Number of SP Groups, Number of PID
Groups
Sets the number of SP groups, number of PID groups
Syntax
SCtrlSPPID,p1,p2,p3
p1
Loop number
p2
SP group number (1 to 8)
p3
PID group number (1 to 8)
Query
SCtrlSPPID[,p1]
Example For loop number L022, set the number of SP
groups to 6 and the number of PID groups to
3.
SCtrlSPPID,L022,6,3
Description
• This command is valid when a PID Control Module is
installed.
SCtrlALNo
Number of Control Alarms
Sets the number of control alarms
Syntax
SCtrlALNo,p1,p2
p1
Loop number
p2
Number of control alarms (1 to 4)
Query
SCtrlALNo[,p1]
Example For loop number L022, set the number of
control alarms to 3.
SCtrlALNo,L022,3
Description
• This command is valid when a PID Control Module is
installed.
SCtrlAlmMode
Alarm Mode
Sets the alarm mode.
Syntax
SCtrlAlmMode,p1,p2
p1
Loop number
p2
Alarm mode
ALM_MODE_ALWAYS
Always active
ALM_MODE_STOP
Not active in
STOP mode
ALM_MODE_STOP_MAN
Not active in
STOP or MAN
mode
Query
SCtrlAlmMode[,p1]
Example For loop number L022, set the alarm mode to
always active.
SCtrlAlmMode,L022,ALM_MODE_ALWAYS
Description
• This command is valid when a PID Control Module is
installed.
2.4 Setting Commands
