u Introduction
n Chemical Cleaning pH Measuring System
Thank you for purchasing Chemical Cleaning pH Measuring System.
To have the system deliver its full capabilities, read this instruction manual thoroughly before you
use it. For safety reasons or to avoid possible damage to your equipment, strictly adhere to every
cautionary note that appears in this manual.
Chemical Cleaning pH Measuring System features automatic chemical cleaning of the pH sensor
without removing pH sensor, while maintaining its performance in pH measurement.
System Conguration of Chemical Cleaning pH Measuring System is as below;
Chemical Cleaning pH Measuring System
pH/ORP Converter 2-wire Analyzer
Chemical Cleaning unit PH8SM3-E PH8SM3-G or PH8SM3-F
pH analyzer PH450G FLXA202 or FLXA21
Distributor ― PH201G
pH sensor
PH8EFP-□-TT2 (Note)
Holder PH8HS3
(Note) You can select WTB10 Terminal Box, if necessary.
This document describes mainly PH8SM3 unit of the system and PH8HS3 Holder. For further
information on other products, please read corresponding manual attached to each product.
The related documents to each product:
General Specications
Product Model Document Name Document number
PH8SM3, PH8HS3, PH201G Chemical Cleaning pH measuring System GS 12B7A1-E
PH450G PH450G pH and Redox (ORP ) Converter GS 12B07C05-01E
FLXA202 FLXA202 2-Wire Analyzer GS 12A01A03-01EN
FLXA21 FLXA21 2-Wire Analyzer GS 12A01A02-01E
PH8EFP, WTB10 pH and ORP Sensors GS 12B07B02-E
* the “E” or “EN” in the document number is a language code.
User’s Manual
Product Model Document Name Document number
PH8SM3, PH8HS3 Chemical Cleaning pH measuring System
IM 12B07W01-04EN(this document)
PH450G PH450G pH and ORP Converter IM 12B07C05-01E
FLXA202, FLXA21 FLXA202/FLXA21 2-Wire Analyzer IM 12A01A02-01E
PH201G PH201G Distributor IM 19B01E04-02E
PH8EFP, PH8EFP, KCI Filling type pH sensor IM 12B7J1-01E
WTB10 WTB10-PH□ Terminal Box IM 19D01B01-01E
* the “E” in the document number is the language code.
n Notes on Handling User’s Manuals
• Please hand over the user’s manuals to your end users so that they can keep the user’s
manuals on hand for convenient reference.
• Please read the information thoroughly before using the product.
• The purpose of these user’s manuals is not to warrant that the product is well suited to any
particular purpose but rather to describe the functional details of the product.
Media No. IM 12B07W01-04EN 1st Edition : Nov. 2016 (YK)
All Rights Reserved Copyright © 2016, Yokogawa Electric Corporation
