YOKOGAWA ROTAMASS Total Insight - 6.5.3 Rotating the terminal box (remote type)

Quick Reference Instruction Manual for Spare
Transmitter replacement
Installation of the Spare transmitter
38 / 76
IM01U10A01-00EN-R, 1
st
edition, 2019-12-09
3. Rotate transmitter housing at angles of 90°, 180° or 270°.
4. Place transmitter housing.
5. Tighten the four fixing screws.
