Quick Reference Instruction Manual for Spare
Transmitter replacement
IM01U10A01-00EN-R, 1
st
edition, 2019-12-09
47 / 76
7.3.6 Set up system related parameters
It is necessary for usage in the plant that the system related parameters like TAGs and
communication Address fit to the system settings. Therefore these settings have to be
adapted in the Universal Spare Transmitter. The Address and TAGs for the exchange de-
vice should be the same as for the defective device in the plant.
Adapt TAG and
Address [HART]
by display:
1. Set user level “Specialist”
2. Go to menu item “[Detailed setup] ► [Dev info] ► [Order info] ► [Tag]”
3. Choose sub menu item “[Tag]”. Put in TAG of the defective transmitter
Choose sub menu item “[Long tag]”. Put in Long TAG of the defective transmitter
1)
4. Set “[Tag]” and “[Long tag]”
5. Go to menu item “[Detailed setup] ► [Dev info] ► [HART info] ► [Poll addr]”
6. Set “[Poll addr]”
1)
The TAG and Long TAG are stored in the “Customer_Setting_...csv”-file attached to the
DVD, microSD of the defective transmitter.
For hardware settings, please refer to the General Instruction Manual
IM 01U10B00-00␣␣-R, chapter 9.4 Advanced settings.
7.4 Wiring
7.4.1 General wiring rules
Be sure to handle the transmitter cover carefully so that there are no damages and for-
eign matter adhesion at its thread and O-ring when it is opened or attached.
DANGER
Life-threatening injuries from electric shock
▶ Switch off power supply.
▶ Secure power supply against inadvertent switch-on.
▶ Check that power supply is free of voltage.
DANGER
Life-threatening injuries from ignition of explosive atmospheres
▶ Wait 20 minutes before opening the housing until the capacitors have discharged
and components have cooled off.
▶ Avoid electrostatically charging the device, e.g. by rubbing it with dry cloths.
DANGER
Explosion hazard in hazardous areas from electrostatic discharge or brush
discharge
Life-threatening injuries or ignition of explosive atmospheres.
▶ Avoid actions that could lead to electrostatic discharges. For example, do not wipe
the coated surface of the transmitter using a piece of cloth.
DANGER
Improper wiring in hazardous areas
When connecting flow meters in hazardous areas, the applicable Explosion Proof Type
Manual must be observed.
WARNING
Risk of injury due to electrical shock
▶ Only have skilled personnel to connect the flow meter.
▶ Do not perform wiring outdoors if it is raining.
