Quick Reference Instruction Manual for Spare
Transmitter replacement
Parameter setting
46 / 76
IM01U10A01-00EN-R, 1
st
edition, 2019-12-09
Depending on the model code of the defective transmitter these parameters should be
adjusted:
Meter size
- - - - /-
RC
1 2 3 4 6 75 9 10 11 12 13 14 158
The following parameter values are recommended to set, if needed:
Tab.7: Overview: setting values for parameters [… lowcut] and [… URV]
Recommend RMTI parameter setting values:
Parameter
name:
[… lowcut]
1)
[… URV]
1)
Meter size: Setting value: Setting value:
Value Unit Value Unit
06 0.0105
kg/h
21.0
kg/h
08 0.0225 45.0
10 0.0850 170.0
15 0.1850 370.0
20 0.4750 950.0
25 0.0800 1600.0
34 1.5000 3000.0
40 2.3500 4700.0
36 5.0000 10000.0
50 10.0000 20000.0
38 16.0000 32000.0
80 25.5000 51000.0
39 50.0000 100000.0
1H 85.0000 170000.0
1F 125.0000 250000.0
2H 250.0000 500000.0
1)
“…” Mass flow low cut and URV values compared to parameter values in table 7.
Mass flow and density accuracy
- - - - /-
RC
1 2 3 4 6 75 9 10 11 12 13 14 158
The parameter [Liquid gas select] has to be set to “Gas” if the mass flow and density
accuracy value is 50 or 70.
