Quick Reference Instruction Manual for Spare
Introduction
Scope of application
4 / 76
IM01U10A01-00EN-R, 1
st
edition, 2019-12-09
1 Introduction
1.1 Scope of application
These instructions apply to the following Rotamass Total Insight product families:
▪ Rotamass Total Insight Spare transmitter and Spare sensor.
1.2 Target group
The following persons are the target group of this manual:
▪ Technicians
▪ Engineers
This manual along with its applicable documents enables the target group to replace an
existing Rotamass Total Insight sensor or transmitter by completing the following steps:
▪ Dismantling
▪ Installation
▪ Configuration (parametrization)
▪ Wiring
▪ Commissioning
For general installation instructions please refer to the General Instruction Manual
IM 01U10B00-00␣␣-R.
1.3 Applicable documents
The following documents supplement this manual:
▪ Explosion Proof Type Manual (Ex-IM) IM01U10X␣␣-00␣␣-R
▪ Software Instruction Manual (SW-IM) IM01U10S␣␣-00␣␣-R
▪ General Specifications (GS) GS01U10B␣␣-00␣␣-R
▪ Dry Verification procedure MP 208-008-2019
▪ General Instruction Manual IM 01U10B00-00␣␣-R
1.4 Contact information
For more information or questions, contact your local Yokogawa sales organization.
1.5 Explanation of safety instructions and symbols
Signal words
Warning notices are intended to alert users to potential hazards when working with the
flow meter. There are four hazard levels that can be identified by the signal word:
Signal word Meaning
DANGER
Identifies a high-risk hazard resulting in death or severe injury
unless avoided.
WARNING
Identifies a fluid-risk hazard that may lead to death or severe in-
jury unless avoided.
CAUTION
Identifies a low-risk hazard that may lead to minor or moderate
injury unless avoided.
NOTICE Identifies a hazard resulting in property damage.
