YOKOGAWA WT1803 User Manual

17-5
IM WT1801-01EN
Save Conditions (File Settings)
• Stored measurement data is saved to files in binary format (with .wts extensions).
• Measurement conditions, settings, and storage information are saved in binary format to header files (with
.hds extensions).
• File name extensions are added automatically
.
• When the storage destination is a USB memory device, the maximum stored data file (.wts) file size is 1 GB.
• You cannot load stored data using the WT1800.
Click here.
Displaying a File List and Specifying the Save Destination (File List)
On the file list, specify the save destination. You can set the storage medium to the internal RAM disk or to
a USB memory device. You cannot set the storage medium to a network drive. For information about how to
configure the file list display and how to operate files and folders, see “File Operations (Utility).”
Click here.
If you set the storage medium to a USB memory device, when you remove the USB memory device, the
storage medium automatically changes to the internal RAM disk.
Automatic CSV Conversion (Auto CSV Conversion)
You can choose whether to automatically create an ASCII format stored data file (.csv) from the stored data file
(.wts) and the header file (.hds) that are saved when storage finishes or is reset.
• When the storage destination is the internal RAM disk ([RAM-
0])
A CSV file is created in the root folder of the USB memory device whose ID number is 0 ([USB-0]).
• When the storage destination is a USB memory device ([USB-0] or [USB-1])
A CSV file is saved in the same folder as the stored data file.
Automatic File Naming (Auto Naming)
This is the same as the auto naming feature for saving and loading data.
Click here.
File Name (File Name)
This is the same as the file name setting for saving and loading data.
Click here.
Comment (Comment)
This is the same as the comment setting for saving and loading data.
Click here.
Manually Converting to CSV Format (CSV Convert)
You can convert the selected stored data to ASCII format (.csv). This menu item appears when you press File
List to display the file list.
• When you convert stored data on the internal RAM disk ([RAM
-0])
A CSV file is created in the root folder of the USB memory device whose ID number is 0 ([USB-0]).
• When you convert stored data on a USB memory device ([USB-0] or [USB-1])
A CSV file is saved in the same folder as the stored data file you are converting.
17 Data Storage
