YOKOGAWA WT1803 User Manual

18-3
IM WT1801-01EN
File Save Conditions
Displaying a File List and Specifying the Save Destination (File List)
On the file list, specify the save destination. For information about how to configure the file list display and how
to operate files and folders, see “File Operations (Utility).”
Click here.
Saved Items (Item Settings)
This menu item only appears when you select Save Numeric.
Displayed Numeric Items (Displayed Numeric Items)
The saved items vary as indicated below depending on the display.
• When Numeric V
alues Are Displayed in the 4-, 8-, or 16-Value Display or the Matrix Display
All the measurement functions on the page that is displayed when saving starts are saved in the order that
they are displayed.
• When Numeric V
alues Are Displayed in the Single or Dual Harmonics List
In addition to the data described above, the data of harmonics that are not displayed on the screen is saved
up to the maximum measurable order (Max Order).
• When Numeric V
alues Are Displayed in the All Items or Custom Display
The data cannot be saved. If you attempt to save the data, an error message is displayed.
• In Non-Numeric Displays (Waveform display, trend display, etc.)
The WT1800 saved data according to the numeric display settings. For example, when the waveform
display is shown, if the 16-value display would appear when you pressed NUMERIC, then the data for the
measurement functions on the page of the 16-value display that would appear is saved.
Selected Items (Selected Items)
You can select the types of numeric data to save.
Items (Items)
If you selected Selected Items, select which numeric data to save.
• Element (Element)
T
o select an element or wiring unit that you want to store the data of, select or clear its check box. You can
select from the following options.
Element1, Element2, Element3, Element4, Element5, Element6, ΣA, ΣB, and ΣC
•
Function (Function)
Select whether to store the data of a function by selecting or clearing its check box. You can select any of the
measurement function types listed under “Items That This Instrument Can Measure.”
Click here.
• Selecting All Functions (All ON)
The data of all measurement functions is saved.
• Deselecting All Functions (All OFF)
None of the data for any of the measurement functions is saved.
• Preset 1 (Preset 1)
The data of the following measurement functions is saved for all elements and wiring units.
*
Urms, Irms, FreqU, FreqI, P, S, Q, λ, and Φ
• Preset 2 (Preset 2)
The data of the following measurement functions is saved for all elements and wiring units.
*
WP, WP+, WP–, q, q+, q–, Time, WS, and WQ
* If the wiring system setting (Wiring) is configured so that a wiring unit does not exist, the data for the
functions of that wiring unit is not saved. For example, if ΣC does not exist, the data for ΣC is not saved.
18 Saving and Loading Data
