20-3
IM WT1801-01EN
• If you specify a number of measurement functions as items to be printed, it may take a long time to print
the data. Set the print interval to a time that is longer than the time required to print the data.
• If you touch the keys or execute communication commands du
ring printing, printing may slow down.
Scheduled Start and Stop Times (Real Time Control)
You can configure these settings when Print Mode is set to Real Time. You can set the year, month, day, hour,
minute, and second of the print start and stop times. Be sure to set the scheduled printing stop time to a time
after the printing start time.
You can set the values within the following ranges.
•
Y
ear: Any four-digit Gregorian calendar value
• Hour:Minute:Second: 00:00:00 to 23:59:59
• Now: The scheduled printing start time is set to the current time.
• Copy: The scheduled printing start time is copied into the scheduled printing stop time.
• You can set the day for the scheduled start or stop time in February to a value as high as the 31st day. If
you do so, an error message will appear when you enable automatic printing. Reset the scheduled start
and stop times.
•
The WT1800 recognizes leap years when it executes automat
ic printing.
Trigger Event (Trigger Event)
You can configure this setting when Print Mode is set to Event. You can select an event from Event1 to Event8.
Printing is executed whenever the user-defined event specified here occurs.
Printing of the Data at Print Start (Print At Start)
This setting is valid when Print Mode is set to Interval, Real Time, or Integ Sync.
Select whether to print the data at print start.
Comment (Comment)
This is the same as the comment setting for saving and loading data.
Paper Feed (Paper Feed)
Each time you press Paper Feed, the paper roll is fed through by approximately 3 cm.
20 Printing Screen Images and Numeric Data (Option)
To Next Page
