All Items Display (All Items)
You cannot change individual measurement functions. Change the display by pressing PAGE UP and PAGE
DOWN or the up and down cursor keys.
The number of displayed pages varies as indicated below depending on the installed options.
Harmonic Measurement Option or Simultaneous
Dual Harmonic Measurement Option
Installed Not installed
Delta computation option Installed 12 pages 8 pages
Not installed 12 pages 7 pages
Order (Order (k); option)
This setting is valid on the 9
th
or 10
th
page. On the 9
th
or 10
th
page, the order setting appears in the upper left of
the screen. This is the same as setting the order in the 4-, 8-, and 16-value displays.
Click here.
Turning the Display of the Numeric Data for All Elements and Wiring Units On and Off
(Display All Elements)
• OFF
The numeric data is displayed in six columns. If there is a total of seven or more elements and wiring units,
you can change the displayed elements and wiring units by pressing the left and right cursor keys.
• ON
When there is a total of 7 or more elements and wiring units, a
ll the numeric data for the elements and wiring
units is displayed in nine columns. If you select ON when the total number of elements and wiring units is six
or less, the display is the same as when OFF is selected.
Turning the Display Frame On and Off (Display Frame)
This is the same as turning the display frame on and off in the 4-, 8-, and 16-value displays.
Click here.
7 Numeric Data Display
