Element (Element/Σ)
• You can select the element/wiring unit from the options below. The available options vary depending on the
installed elements.
Element1, Element2, Element3, Element4, Element5, Element6, ΣA, ΣB, and ΣC
•
If the selected wiring unit does not have any elements assigned to it, because there is no data, “-------” (no
data) is displayed. For example, if elements are assigned to ΣA but not to ΣB, the measurement function for
ΣB is displayed as “-------” (no data).
Directly Selecting Elements (ELEMENT)
When the menu is not displayed, you can change the element number of the selected measurement function by
pressing ELEMENT.
Changing Elements Simultaneously (ALL)
You can change the elements and wiring units of all displayed items at once. The ALL indicator illuminates.
Order (Order; option)
When you select a function that has harmonic data, you can set the displayed harmonic order within the
following range.
Total (Total value) or 0 (dc) to 500
The orders that can be specified vary depending on the measurement function. For details, see “Harmonic
Measurement Function Orders.”
Click here.
The numeric data corresponding to harmonic orders above the maximum measurable harmonic order is
displayed as “-------” (no data). For information about the maximum measurable harmonic order, see “Maximum
Harmonic Order to Be Measured (Max Order).”
Click here.
Resetting the Display Items (Reset Items)
Reset Patterns (Reset Pattern)
You can select the reset method from the following options.
• Element Origin:
The numeric data for each element is displayed on each page. The pattern that the data is
arranged in varies depending on the number of installed elements.
• Function Origin:
The numeric data for each function is displayed on each page. The pattern that the data is
arranged in varies depending on the number of installed elements.
• Clear Current Page:
All the display items on the current page are set to None.
• Clear All Pages: All the display items on every page are set to None.
Resetting the Items (Reset Items Exec)
Reset the items.
Turning the Display Frame On and Off (Display Frame)
Set whether to show the display frame.
7 Numeric Data Display
