Display Items (ITEM)
Number of Columns (Column Num)
You can select four or six columns.
Column Number (Column No.)
Select the number of the column that you want to configure.
Element (Element/Σ)
This is the same as the element (Element/Σ) item in the Matrix display.
Directly Selecting Elements (ELEMENT)
This is the same as direct element selection in the 4-, 8-, and 16-value displays.
Resetting the Settings (Reset Items Exec)
Reset the column settings.
Turning the Display Frame On and Off (Display Frame)
This is the same as turning the display frame on and off in the 4-, 8-, and 16-value displays.
Displaying Peak Over-Range Occurrence Information (Display Peak Over Status)
You can select whether to show (ON) or hide (OFF) peak over-range occurrence information.
Peak Over-Range Occurrence Information (Peak Over Status)
• If a peak over-range occurs in an input signal even once from
the time when high speed data capturing starts
until it stops, the input signal is displayed in red.
Display example for when a peak over-range has occurred in U1 and I2.
• When display frames for measured values are displayed, display frames of measured values within which a
peak over-range has occurred are displayed in red.
• Even if you stop high speed data capturing, the peak over-ran
ge occurrence information does not disappear.
The peak over-range occurrence information will disappear (be reset) when after you stop high speed data
capturing, you restart high speed data capturing or change the settings.
The input peak over-range indicator in the center of the top section of the screen lights in red when a peak
over-range occurs.
