7 Numeric Data Display
Custom Display (Custom)
Loading a Display Configuration File (Load Items)
On the file list, specify a file to load display configuration data from. The extension is .TXT.
For information about how to configure the file list display and how to operate files and folders, see “File
Operations (Utility).”
Loading a Background File (Load Bmp)
On the file list, specify a background file to load. The extension is .BMP.
If you use a commercial graphics program to create an image that meets the following specifications, you can
load the image to the WT1800.
•
File format:
BMP
• Resolution: 800 × 672 pixels
• Color scale: 16-bit high color (R: 5 bits, G: 6 bits, B: 5 bits) or 24-bit true color (R: 8 bits, G: 8 bits, B: 8 bits)
• Size: Approx. 1 MB (16 bit) or approx. 1.6 MB (24 bit)
• If you attempt to load an image that does not meet the above specifications, the image will not be displayed
properly, or an error message will appear and you will not be able to load the image.
• After you properly load a display configuration file and a backg
round file, if you restart the WT1800 and the
same background file is not in the same location, the background will return to its default.
Simultaneously Loading a Display Configuration File and a Background File (Load
Items & Bmp)
When you select a display configuration file (.TXT) from the file list and load it, if there is a background file with a
.BMP extension and the same name as the display configuration file, that file is also loaded.
If there is no background file with the same name as the display configuration file in the same directory as the
display configuration file, an error occurs.
Display Configuration (Edit Items)
Total Number of Items (Total Items)
You can set the total number of numeric data boxes to display to a number from 1 to 192.
*
Number of Items per Page (Items Per Page)
You can set the total number of numeric data boxes to display per page to a number from 1 to 192.
*
The total number of pages is Total Items/Items Per Page.
* The ranges of Total Items and Items Per Page are related as indicated below.
• Total Items: Items Per Page to Items Per Page × 12
• Items Per Page: Total Items/12 to Total Items
To Next Page
