7-1
IM WT1801-01EN
7 Numeric Data Display
Numeric Data Display (NUMERIC)
You can press NUMERIC to make the numeric data display appear.
Each time you press NUMERIC the display format switches in order between 4 Items, 8 Items, 16 Items, Matrix,
All Items, Hrm List Single, Hrm List Dual, and Custom.
Display Format (FORM)
The display format options vary depending on the current display.
• Numeric data display format
• Waveform display format
• Trend display format
• Bar graph display format
• Vector display format
• Setup parameter list display format
• High speed data capturing settings
Numeric Data Display Format
You can select the number of numeric data items that are displayed simultaneously from the choices below or
choose to display a list of items.
4-Value Display (4 Items)
Four numeric data values are displayed in one column.
8-Value Display (8 Items)
• When the display mode is Numeric, eight numeric data values
are displayed in one column.
• When the display is split, eight numeric data values are displayed in two columns.
16-Value Display (16 Items)
Sixteen numeric data values are displayed in two columns.
Matrix (Matrix) and All (All Items) Displays
A table of numeric data is displayed with measurement functions listed vertically and symbols indicating
elements and wiring units listed horizontally. The number of displayed items varies depending on the number of
elements that are installed in the WT1800.
