19 Saving Screen Images
You can save screen image data to files in BMP, PNG, and JPEG formats.
Conditions for Saving Screen Image Data (IMAGE SAVE MENU)
File List Display and Save Destination Settings (File List)
On the file list, specify the save destination. For information about how to configure the file list display and how
to operate files and folders, see “File Operations (Utility).”
When you turn off the WT1800 power, the contents of the internal RAM disk are lost. Save the contents of the
RAM disk to a USB memory device or network drive before you turn off the WT1800.
Format of Screen Image Data (Format)
You can select the format to save to from the options listed below.
• BMP: The extension is .BMP. The file size is approximately 100 KB for black and white mode and
approximately 1.5 MB for color mode.
• PNG:
The extension is .PNG. The file size is approximately 25 KB for black and white mode and
approximately 100 KB for color mode.
• JPEG:
The extension is .JPG. The file size is approximately 200 KB for color mode.
The file sizes listed here are for reference. Actual file sizes will vary depending on the image that is saved.
Screen Image Colors (Color)
You can select the color format to save to from the options below.
• OFF: Data is saved in black and white.
• Color: Data is saved in 65536 colors.
• Reverse: Data is saved in 65536 colors. The image background is set to white.
• Gray: Data is saved in 16 grayscale levels.
Automatic File Naming (Auto Naming)
This is the same as the auto naming feature for saving and loading data.
File Name (File Name)
This is the same as the file name setting for saving and loading data.
Comment Displayed at the Bottom of the Screen (Comment)
This is the same as the comment setting for saving and loading data.
Saving a Screen Image (IMAGE SAVE)
Save the screen image to a file.
