7-7
IM WT1801-01EN
Matrix display (Matrix)
Item Number to Set (Item No.)
This is the same as setting the item number in the 4-, 8-, and 16-value displays.
Function (Function)
This is the same as setting the function in the 4-, 8-, and 16-value displays.
In the matrix display, if you choose a measurement function that does not require an element or wiring unit (such
as η1 to η4, F1 to F20, Ev1 to Ev8, etc.), data is displayed in the first column.
Direct Function Selection (U/I/P, S/Q/λ/Φ, WP/q/TIME, FU/FI/η, and U/I MODE)
This is the same as direct function selection in the 4-, 8-, and 16-value displays.
Order (Order; option)
This is the same as setting the order in the 4-, 8-, and 16-value displays.
Resetting the Display Items (Reset Items)
This is the same as resetting the display items in the 4-, 8-, and 16-value displays.
Columns (Column Settings)
Number of Columns (Column Num)
You can set the number of columns to 4 or 6.
Column Number (Column No.)
Select the number of the column that you want to configure.
Element (Element/Σ)
•
Y
ou can select the element/wiring unit from the options below. The available options vary depending on the
installed elements.
None, Element1, Element2, Element3, Element4, Element5, Element6, ΣA, ΣB, and ΣC
•
If you select None, no measurement data is displayed in the selected column.
• If the selected wiring unit does not have any elements assigned to it, because there is no data, “-------” (no
data) is displayed. For example, if elements are assigned to ΣA but not to ΣB, the measurement function for
ΣB is displayed as “-------” (no data).
Directly Selecting Elements (ELEMENT)
This is the same as direct element selection in the 4-, 8-, and 16-value displays.
Resetting the Settings (Reset Items Exec)
Reset the column settings.
Turning the Display Frame On and Off (Display Frame)
This is the same as turning the display frame on and off in the 4-, 8-, and 16-value displays.
7 Numeric Data Display
