8-3
IM WT1801-01EN
Delta Computation (Option)
Δ
U1( ): DELTAU1( )
Δ
I( ): DELTAI( )
Δ
P1( ): DELTAP1( )
Δ
U2( ): DELTAU2( )
–––
Δ
P2( ): DELTAP2( )
Δ
U3( ): DELTAU3( )
–––
Δ
P3( ): DELTAP3( )
Δ
U
Σ
( ): DELTAUSIG( )
–––
Δ
P
Σ
( ): DELTAPSIG( )
Δ
U1rms( ): DELTAU1RMS( )
Δ
U1mean( ): DELTAU1MN( )
Δ
U1rmean( ): DELTAU1RMN( )
Δ
U2rms( ): DELTAU2RMS( )
Δ
U2mean( ): DELTAU2MN( )
Δ
U2rmean( ): DELTAU2RMN( )
Δ
U3rms( ): DELTAU3RMS( )
Δ
U3mean( ): DELTAU3MN( )
Δ
U3rmean( ): DELTAU3RMN( )
Δ
U
Σ
rms( ): DELTAUSIGRMS( )
Δ
U
Σ
mean( ): DELTAUSIGMN( )
Δ
U
Σ
rmean( ): DELTAUSIGRMN( )
Δ
U1dc( ): DELTAU1DC( )
Δ
U1ac( ): DELTAU1AC( )
Δ
Irms( ): DELTALRMS( )
Δ
U2dc( ): DELTAU2DC( )
Δ
U2ac( ): DELTAU2AC( )
Δ
Imean( ): DELTAIMN( )
Δ
U3dc( ): DELTAU3DC( )
Δ
U3ac( ): DELTAU3AC( )
Δ
Irmean( ): DELTAIRMN( )
Δ
U
Σ
dc( ): DELTAUSIGDC( )
Δ
U
Σ
ac( ): DELTAUSIGAC( )
Δ
Idc( ): DELTAIDC( )
––– –––
Δ
Iac( ): DELTAIAC( )
Motor Evaluation (Option)
Speed: SPEED( ) Torque: TORQUE( ) Pm: PM( )
Slip: SLIP( ) SyncSp: SYNC( ) EaU: EAU( )
EaI: EAI( ) ––– –––
Auxiliary Input (Option)
Aux1: AUX1( ) Aux2: AUX2( )
Setting Operand Parameters
The parameters that you need to enter depend on whether the function is followed by “( , )” or “( )”.
Setting Parameters for Functions Followed by “( , )”
Specify the element to the left of the comma, and specify the harmonic order to the right of the comma. For
example: (E1,OR2).
Symbols used to represent elements
E1 to E6:
Elements 1 to 6
E7 to E9: Wiring units ΣA to ΣC
Symbols that indicate the harmonic order (Order)
*
ORT: Total value
OR0: dc
OR1: Fundamental wave
OR2 to OR500: Harmonic orders 2 to 500
* On models with the harmonic measurement option or the simultaneous dual harmonic measurement
option.
Setting Parameters for Functions Followed by “( )”
Specify the element.
You do not need to specify a harmonic order. For example: (E1).
For information about the parameters that you can use with each operand, see appendix 6 in the getting started
guide, IM WT1801-03EN.
8 Computation
