YOKOGAWA ZR402G User Manual

<10. Other Functions>
10-10
IM 11M12A01-04E 11th Edition : Jul. 19, 2017-00
Table 10.7 Parameter Codes for Oxygen Analyzer
Display-related Items in Group A
Code Item
Engineering
unit
Code Item
Engineering
unit
A00 Selection
of display
items
0 Oxygen concentration A50 Span correction ratio 0 %
1 Oxygen analyzer (0.0) A51 Span correction ratio 1 %
2 Oxygen analyzer (0.0) A52 Span correction ratio 2 %
3 Analog output selected A53 Span correction ratio 3 %
A01 Oxygen concentration % O
2
A54 Span correction ratio 0 %
A02 A55 Span correction ratio 3 %
A03 A56 Span correction ratio 2 %
A04 A57 Span correction ratio 1 %
A05 A58 Span correction ratio 2 %
A06 Air ratio A59 Span correction ratio 1 %
A07 Cell temperature °C A60 Zero correction ratio 0 %
A08 Cold junction temperature °C A61 Zero correction ratio 1 %
A09 Meas. gas temperature °C A62 Zero correction ratio 2 %
A10 Amount of water vapor in % exhaust
gas
% A63 Zero correction ratio 3 %
A11 Cell voltage mV A64 Zero correction ratio 4 %
A12 TC voltage mV A65 Zero correction ratio 5 %
A15 Cold junction voltage mV A66 Zero correction ratio 6 %
A16 Output current mA A67 Zero correction ratio 7 %
A20 Cell response time Seconds A68 Zero correction ratio 8 %
A21 Cell internal resistance Ω A69 Zero correction ratio 9 %
A22 Cell robustness A70 Calibration history 0 YY.MM.DD/
HH.MM
A23 Heater on-time ratio % A71 Calibration history 1 YY.MM.DD/
HH.MM
A24 Oxygen concentration (with time
constant)
% O
2
A72 Calibration history 2 YY.MM.DD/
HH.MM
A25 A73 Calibration history 3 YY.MM.DD/
HH.MM
A26 A74 Calibration history 4 YY.MM.DD/
HH.MM
A30 Max. oxygen concentration % O
2
A75 Calibration history 5 YY.MM.DD/
HH.MM
A31 Occurrence of maximum oxygen
concentration
YY.MM.DD/
HH.MM
A76 Calibration history 6 YY.MM.DD/
HH.MM
A32 Min. oxygen concentration % O
2
A77 Calibration history 7 YY.MM.DD/
HH.MM
A33 Occurrence of minimum oxygen
concentration
YY.MM.DD/
HH.MM
A78 Calibration history 8 YY.MM.DD/
HH.MM
A34 Average oxygen concentration % O
2
A79 Calibration history 9 YY.MM.DD/
HH.MM
A35 A80 Time YY.MM.DD/
HH.MM
A36 A90 Software revision
Note1: “/” indicates that both are displayed alternately.
Note2: Parameter codes with no items in the above table are not used in the oxygen analyzer.
