7.8.2 Humidity Analyzer - Setting Display Item
Display items are those items that are displayed on the basic panel display. Parameter code A00
or F08 is used to set the display items as shown in the table below. If the humidity analyzer /HS
option was specied at the time of purchase, the equipment is a humidity analyzer. For other than
the above, the equipment is set to oxygen concentration at the factory before shipment. If mix
ratio is to be measured, change the existing setting as follows.
Additionally, when humidity analyzer is selected in the Detector Type Setting in the previous
section, the display item will be humidity if data initialization is performed.
Table 7.8 Display Item
Values set with A00 or F08 Items displayed on the basic panel display
0 Indicates the oxygen concentration.
1 Indicates the humidity.
2 Indicates the mix ratio.
3 Displays an item for the current output.
If the output damping has been set for the current output, values
involving the output damping are displayed.
7.9 Checking Current Loop
The set current can be output as an analog output. This enables the checking of wiring between
the converter and the receiving instrument. Current loop checking is performed using parameter
code “G01”.
Table 7.9 Checking Current Loop
Switch operation Display Description
> ∧
ENT
A01
Display after the password has been entered.
> ∧
ENT
G01
Touch the [∧] key to switch to Group G.
> ∧
ENT
00.0
Touch the [ENT] key. The output current remains preset with the output-
hold feature (Section 2.3).
> ∧
ENT
10.0
Touch the [∧] key to set the numeric value 1 (to set a 10-mA output).
> ∧
ENT
10.0
Touch the [ENT] key to have all the digits ash.
> ∧
ENT
10.0
Touch the [ENT] key again to stop the ashing.
A 10-mA output is then issued.
> ∧
ENT
G01
Touch the [ENT] key once again to switch to the parameter code selection
display.
At that point, the output current returns to the normal value.
> ∧
ENT Basic
panel
display
Touch the [>] key together with the [ENT] key to return to the basic panel
display.
The symbol [ ] indicates that the key is being touched. Light characters indicates that the digits are ashing.
