<5. Wiring>
5-6
IM 11M12A01-04E 11th Edition : Jul. 19, 2017-00
5.5.1 Cable Specications
Use a 2-core or 3-core cable for this wiring. Depending on the number of input(s), determine
which cable to use.
5.5.2 Wiring Procedure
(1) M4 screws are used for the terminal of the converter. Each cable should be equipped with
the corresponding crimp contact.
(2) The ON/OFF level of this contact input is identied by the resistance. Connect a contact
input that satises the descriptions in Table 5.2.
Table 5.2 Identication of Contact Input ON/OFF
Closed Open
Resistance 200 Ω or less 100 kΩ or more
To Next Page
