YOKOGAWA ZR402G User Manual

<10. Other Functions>
10-14
IM 11M12A01-04E 11th Edition : Jul. 19, 2017-00
Equipment Setup and Others in Group F
Code Item Tuning Engineering unit Default setting
F01 Equipment setup 0 Oxygen analyzer Oxygen analyzer
1 Humidity analyzer
F02 Selection of measurement
gas
0 Wet Wet
1 Dry
F04 Selection of temperature
units
0 degree C degree C
1 degree F
F05 Selection of pressure units 0 kPa kPa
1 psi
F08 Selection of display items 0 Oxygen concentration Oxygen
concentration
1 Amount of moisture quantity
2 Mixed ratio
3 Item selected with analog output
F10 Date YY.MM.DD/
HH.MM
F11 Period over which average
values are calculated
1 to 255 hours Hours One hour
F12 Period over which max. and
min. values are monitored
1 to 255 hours Hours 24 hours
F15 Purging time 0 to 60 minutes Minutes 0 minute
F20 Amount of water vapor in
exhaust gas
0 to 5 m
3
/kg (m
3
) 1.0 m
3
/kg (m
3
)
F21 Theoretical amount of air 0 to 20 m
3
/kg (m
3
) 1.0 m
3
/kg (m
3
)
F22 X value 0 to 19.99 1
F23 Absolute humidity of the
atmosphere
0 to 1 kg/kg 0.1 kg/kg
F30 Initializing all data
F31 Initializing data in group A
F32 Initializing data in group B
F33 Initializing data in group C
F34 Initializing data in group D
F35 Initializing data in group E
F36 Initializing data in group F
Inspection-related Items in Group G
Code Item Tuning Engineering unit Default setting
G01 mA-output loop 4 to 20 mA 4 mA
G11 Output contact 1 0 Open Open
1 Closed
G12 Output contact 2 0 Open Open
1 Closed
G15 Automatic calibration
solenoid valve (zero)
0 Off Off
1 On
G16 Automatic calibration
solenoid valve (span)
0 Off Off
1 On
G21 Input1 contact 0 Open
1 Closed
G22 Input2 contact 0 Open
1 Closed
G30 Reset
