Alarm-related Items in Group D
Code Item Tuning Engineering unit Default setting
D01 Oxygen concentration,
high-high alarm setpoint
0 to 100 % O
2
100% O
2
D02 Oxygen concentration,
high alarm setpoint
0 to 100 % O
2
100% O
2
D03 Oxygen concentration,
low alarm setpoint
0 to 100 % O
2
0% O
2
D04 Oxygen concentration,
low-low alarm setpoint
0 to 100 % O
2
0% O
2
D05 Humidity, high-high alarm
setpoint
0 to 100 %H
2
O 100 %H
2
O
D06 Humidity, high alarm
setpoint
0 to 100 %H
2
O 100 %H
2
O
D07 Humidity, low alarm
setpoint
0 to 100 %H
2
O 0 %H
2
O
D08 Humidity, low-low alarm
setpoint
0 to 100 %H
2
O 0 %H
2
O
D11 Mixing ratio, high-high
alarm setpoint
0 to 1 kg/kg 1 kg/kg
D12 Mixing ratio, high alarm
setpoint
0 to 1 kg/kg 1 kg/kg
D13 Mixing ratio, low alarm
setpoint
0 to 1 kg/kg 0 kg/kg
D14 Mixing ratio, low-low
alarm setpoint
0 to 1 kg/kg 0 kg/kg
D30 Oxygen concentration
alarm hysteresis
0 to 9.9 % O
2
0.1% O
2
D31 Humidity alarm hysteresis 0 to 9.9 %H
2
O 0.1 %H
2
O
D32 Mixing ratio alarm
hysteresis
0 to 0.1 kg/kg 0.001 kg/kg
D33 Delayed alarm action 0 to 255 Seconds 3 seconds
D41 Oxygen concentration,
high-high alarm detection
0 Not detected Not detected
1 Detection
D42 Oxygen concentration,
high alarm detection
0 Not detected Not detected
1 Detection
D43 Oxygen concentration,
low alarm detection
0 Not detected Not detected
1 Detection
D44 Oxygen concentration,
low-low alarm detection
0 Not detected Not detected
1 Detection
D45 Humidity, high-high alarm
detection
0 Not detected Not detected
1 Detection
D46 Humidity, high alarm
detection
0 Not detected Not detected
1 Detection
D47 Humidity, low alarm
detection
0 Not detected Not detected
1 Detection
D48 Humidity, low-low alarm
detection
0 Not detected Not detected
1 Detection
D51 Mix ratio, high-high alarm
detection
0 Not detected Not detected
1 Detection
D52 Mix ratio, high alarm
detection
0 Not detected Not detected
1 Detection
D53 Mix ratio, low alarm
detection
0 Not detected Not detected
1 Detection
