<7. Startup>
7-7
IM 11M12A01-04E
(2) Entering numeric values such as oxygen concentration values and factors
Switch operation Display Description
> ∧
ENT
00.0
The set value is displayed after the parameter code selection.
An example of entering "9.8" is given below. (The currently set value is
0.0)
> ∧
ENT
00.0
Touch the [>] key to move the position of the digit that is ashing to the
digit to be changed.
Continuously touch the [>] key, and the position of the digit that is ashing
will move continuously to the right.
> ∧
ENT
09.0
Touch the [∧] key to set the numeric value 9.
Continuously touch the [∧] key, and the numeric value will change in
sequence from 0 to 1 to 2 to 3 … to 8 to 9 and back to 0.
> ∧
ENT
09.0
Touch the [>] key to move the position of the digit that is ashing to the
right.
> ∧
ENT
09.8
Touch the [∧] key to set the numeric value 8.
> ∧
ENT
09.8
Where the correct numeric value is displayed, touch the [ENT] key.
> ∧
ENT
09.8
If you touch the [ENT] key again, the ashing stops and the current set
value will be in effect.
> ∧
ENT
C11
Touch the [ENT] key once again to return to the parameter code
selection display.
(3) If invalid numeric values are entered.
Switch operation Display Description
> ∧
ENT
98.0
If an invalid numeric value (beyond the input range specied) is entered,
"Err" will appear for two seconds after touching the [ENT] key.
> ∧
ENT
Err
> ∧
ENT
00.0
"Err" appears for two seconds, and the display returns to the rst set
value.
Re-enter the numeric value.
11th Edition : Jul. 19, 2017-00
