York YCIV Series - TABLE 30 - Values Required for BAS Communication; TABLE 31 - Real Time Error Numbers

JOHNSON CONTROLS
293
SECTION 8 - MICROPANEL
FORM 201.23-NM2
ISSUE DATE: 09/25/2020
8
TABLE 31 - REAL TIME ERROR NUMBERS
ERROR NUMBER
(##)
DESCRIPTION
0 ALL OK
1 DATUM TYPE OK TEST FAILED
2 ENGLISH TEXT TOO LONG
3 FLOATING POINT EXCEPTION
4 GET PACKET FAILED
5 GET TYPE FAILED
6 INVALID UNIT CONVERSION
7 INVALID HARDWARE SELECTION
8 REAL TIME FAULT
9 SPANISH TEXT TOO LONG
10 THREAD EXITED
11 THREAD FAILED
12 THREAD STALLED
13 IO BOARD RESET
14 BRAM INVALID
15 BACNET SETUP FAILED
TABLE 30 - VALUES REQUIRED FOR BAS COMMUNICATION
SETTING DESCRIPTION
Protocol
BACnet MS/TP Modbus RTU
5
YorkTalk 2
DE MODIFIER ADDRESS 0 to 41943
(3)
1 -1
DE MODIFIER OFFSET 0 to 99
(4)
0 N/A
P1 PROTOCOL BACNET N/A N/A
P1 MANUAL MAC ADDRESS 0-127
(1)
N/A N/A
P1 BAUD RATE 9600 To 76800 or Auto Selectable
(1)
N/A N/A
P1 PARITY NONE N/A N/A
P1 STOP BITS 1 N/A N/A
P2 PROTOCOL N/A MODBUS SVR N/A
P2 MANUAL MAC ADDRESS N/A 0-127
(1)
N/A
P2 BAUD RATE N/A 19,200
(2)
N/A
P2 PARITY N/A NONE
(2)
N/A
P2 STOP BITS N/A 1 N/A
P2 HW SELECT BIT N/A RS-485 or RS-232
(1)
N/A
RESET REAL TIME ERROR N/A N/A N/A
P1 HW SELECT BIT N/A N/A N/A
CHILLER ID N/A N/A 0
1
as Required By Network
2
or Other As Required By Network
3
number Is Multiplied By 100, Set As Required By Network
4
number Is Added To De Modier Address, Set As Required By Network
5
unit Operating Software Version C.Mmc.13.03 Or Later Required For Modbus Protocol
The table below shows set-up requirements for each
communication protocol.
Reboot required (cycle power) after set-
tings are changed.
Table 31 on page 293 shows the real time error num-
bers that may be encountered during communication
setup and a description of each.
