Owner’s Manual | PCAS XRX
APPENDICES 57
Antenna Array
Type Directional capable, internal, multi-element directional array
Number of Antennas 4
Open Space ±8.2°
Obstruction ±30°
Sense Amplitude / Phase
Phase Balance ±12°
Amplitude Balance ±0.5 dB
Phi Range >65°
Polarization Cross
Gain +2.2 dBi
Display
Type FSTN Liquid Crystal Display, Black/White, Wide Temp
Resolution 122 x 32
Viewing Angle 12:00
Backlight Blue-White Electroeluminesence
Audio
Impedance 300 ohms x 2 channels or 600 ohms x 1 channel, selectable
Power 4.0 watts max. @ 2.5 volts peak-to-peak
Compatibility Stereo / Mono selectable, ground isolation or connection
Storage
Temperature Min: -40°C (-40°F) Max: +85°C (185°F)
Accessories
A complete line of accessories is available from your local avionics or pilot supply store, or through Zaon direct.
