Page – 104/155 AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual
Error code Effect Condition
Restart
procedure
MDI /
LED
CODE
CAN
OPEN
CODE
ZAPI
CODE
ENCODER D.ERR XX Traction is stopped running Key re-cycle 3 FFA9 169
HOME SENS.ERR XX
MC is opened , EB is applied,
EVP stopped
Running
Key re-cycle
3 FFB0 176
OFFSET SPD.SENS.
EB is applied, Traction/Pump,
valves stopped.
Start-up
Perform ABS
SENS. ACQUIRE
3 FF99 153
PWM ACQ. ERROR
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up Key re-cycle 6 FFA4 164
ED SLIP MISMATCH
MC is opened, EB is applied,
Traction/Pump stopped
Running
Valves or
Traction/Pump
request
7 FFA3 163
WATCHDOG
MC is opened, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Key re-cycle 8 6010 8
EVP DRIVER OPEN
MC is opened (the command is
released), EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves request 9 FFF8 240
EVP COIL OPEN Valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
9 5002 214
EVP DRIV. SHORT.
MC is opened , EB is applied,
EVP stopped
Start-up, stand-by,
running
Traction/Pump
request
9 5003 215
EVP2 DRIVER OPEN
MC is opened (the command is
released), EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves request 10 FFB8 184
EVP2 COIL OPEN Valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
10 50F2 182
EVP2 DRIV. SHORT
MC is opened , EB is applied,
EVP stopped
Start-up, stand-by,
running
Traction/Pump
request
10 50F3 183
STALL ROTOR Traction/Pump stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
11 FFD3 211
CONTROLLER MISM.
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Install the correct
software and Key
re-cycle
12 FFEF 239
EEPROM KO
Controller works using default
parameters
Start-up, stand-by,
running
13 3610 208
PARAM RESTORE
No effect Start-up
Traction/Pump
request
14 0000 209
SEAT MISMATCH
MC is not closed, EB is applied,
Traction/Pump stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
15 FFDE 222
HW FAULT EV.
MC is not closed, EB is applied,
Traction/Pump stopped
Start-up Key re-cycle 16 FFEE 238
LOGIC FAILURE #3
MC is opened, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by
Valves or
Traction/Pump
request
17 FF11 17
LOGIC FAILURE #2
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
Valves or
Traction/Pump
request
18 FF12 18
LOGIC FAILURE #1
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Stand-by, running
Valves or
Traction/Pump
request
19 5114 19
VKEY OFF SHORTED
MC is not closed, EB is applied,
Traction/Pump stopped
Start-up Key re-cycle 20 5101 220
CONT. DRV. EV Valves stopped
Start-up, stand-by,
running
Valves request 21 FFE8 232
DRV. SHOR. EV Valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
21 FFF9 234
OPEN COIL EV.
MC remains closed, EB is
applied, Traction/Pump, valves
stopped (the command is
released)
Start-up, Stand-by,
running
Valves or
Traction/Pump
Request
21 FFF2 242
