Page – 20/155 AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual
Pin Type Name Description
A15 Input CPOT1
Analog input 1.
The default function is as accelerator reference (wiper contact of
the accelerator potentiometer).
A16 Input DI10
Digital input DI10.
The input is activated when it is connected to +B.
The default function is as 2ND input, closing the switch valve EV2
is activated.
A17 Input DI8
Digital input DI8.
The input is activated when it is connected to +B.
The default function is as 1ST input, closing the switch valve EV1
is activated.
A18 Input
DI11 /
CPOT3
Digital input DI11.
The input is activated when the external switch is closed to -B.
The default function is as CUTBACK SPEED 1 input.
In the sense coil version, this input is connected to the AC motor
sense coil.
Hardware can be properly configured as additional analog or
digital input.
A19 Input DI5
Digital input DI5.
The input is activated when it is connected to +B.
The default function is as HORN input. Closing the switch, the
horn is activated.
A20 Input DI6
Digital input DI6.
The input is activated when it is connected to +B.
The default function is as LOWERING input.
A21 Input
DI12 /
CPOT4
Digital input DI12.
The input is activated when the external switch is closed to -B.
The default function is as CUTBACK SPEED 2 input.
In the sense coil version, this input is connected to the AC motor
sense coil.
Hardware can be properly configured as additional analog or
digital input.
A22 Input PTH
Analog input for the thermal sensor of the traction motor.
Internal pull-up consists of a fixed 2 mA (max 5 V) current source.
A23 Output EVP2
Driving output for the second PWM current-controlled electrovalve
(driving to -B).
A24 Output EVP1
Driving output for the first PWM current-controlled electrovalve
(driving to -B).
Default function is as LOWERING valve.
A25 Output PENC
Positive supply for external devices (encoder, potentiometers,
etc.) +12 /+5 V, 150 mA maximum.
A26 Output HORN Driving output for the horn electrovalve (driving to -B). Protected.
