Page – 86/155 AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual
TESTER (Supervisor µC)
Parameter
Unit of measure
(resolution)
Description
A15 POT#1
(A)
Volt (0.01 V) Status of the analog input 1 (pin A15).
A30 POT#2
(A)
Volt (0.01 V) Status of the analog input 2 (pin A30).
D11-A18 POT#3
(A)
Volt (0.01 V) Status of the analog input 3 (pin A18), when the
associated hardware is configured as analog input.
D12-A21 POT#4
(A)
Volt (0.01 V) Status of the analog input 3 (pin A21), when the
associated hardware is configured as analog input.
WARNING SYSTEM
(CO)
- Warning code (in case of warning).
