Accessories
34
Figure 22 Insert WT6000 into Cradle
2. If charging a WT6000 with a extended battery, insert the end of the WT6000 into the WT6000 charging slot as
shown below.
Figure 23 Insert WT6000 with Extended Battery into Cradle
3. Ensure that the WT6000 is properly seated in the charging slot.
Charging the RS6000
To Charge the RS6000:
1. Insert the RS6000 in the RS6000 charging slot.
