Zebra WT6000 Series - Page 53

Accessories
53
Figure 51 Slide top Tray onto Bottom Tray
8. Install 16 M2.5 studs onto top tray as shown below.
Figure 52 Install Studs
9. Align and install 4-Slot Battery Charger onto four studs.
Figure 53 Align Chargers on Studs
10. Connect DC Y cables to four 4-Slot Battery Chargers.
Studs (16)
