Zebra WT6000 Series - Page 65

Accessories
65
7. Slide the mount onto the WT6000.
Figure 71 Install Mount
8. Using a T6 Torx screwdriver, install the three screws that connect the keypad mount to the WT6000
9. Using a T8 Torx screwdriver, install the two screws that connect the keypad to the mount.
Figure 72 Horizontal Installation - Tighten Screws
Torx T8
Screw
Torx T6
Screw
