Zebra WT6000 Series User Manual

DataWedge Configuration
74
Figure 83 Data Capture Plus Dock Button
The DataWedge profile configuration screen allows the user to configure how the DCP appears on the screen once
the particular profile is enabled. The DCP is hidden by default. Enabling DCP option displays additional
configuration parameters.
Figure 84 Data Capture Plus Settings
• Enable - Select to enable Data Capture Plus (default - disabled).
• Dock button on - Select position of the button.
• Left or right - Allows user to place the button on either the right or left edge of the screen.
• Left only - Places the button on left edge of the screen.
• Right only - Places the button on the right edge of the screen.
• Start in - Select the initial DCP state.
• Fullscreen mode - DCP covers the whole screen.
• Button mode - DCP displays as a circular button on the screen and can be switched to fullscreen
mode.
• Button only mode - DCP displays as a circular button on the screen and cannot be switched to
fullscreen mode.
• Button highest position - Select the top of the range the user is allowed to move the DCP, given as a
percent of the screen height (default - 0).
• Button lowest position - Select the bottom of the range the user is allowed to move the DCP, given as a
percent of the screen height (default - 100).
DCP Button

Zebra WT6000 Series Specifications

General

Storage	4 GB Flash
NFC	No
Audio	Built-in speaker and microphone
Operating Temp	-4°F to 122°F (-20°C to 50°C)
Connectivity	802.11a/b/g/n
Durability	IP65
Drop Spec	Multiple 4 ft./1.2 m drops to concrete
Operating System	Android™ 5.1 (Lollipop) with Mobility Extensions (Mx)
