Specifications
Printing Specifications
6/6/08 Z Series
®
/RZ™ Series User Guide 79695L-002 Rev. A
Printing Specifications
Printing Specifications ZM400/RZ400 ZM600/RZ600
Print resolution 203 dots/in. 8 dots/mm 203 dots/in. 8 dots/mm
300 dots/in. 12 dots/mm 300 dots/in. 12 dots/mm
600 dots/in. 24 dots/mm N/A N/A
Dot size
(width x length)
203 dots/in. 0.0049 in. x
0.0049 in.
0.125 mm x
0.125 mm
0.0049 in. x
0.0049 in.
0.125 mm x
0.125 mm
300 dots/in. 0.0033 in. x
0.0039 in.
0.084 mm x
0.099 mm
0.0033 in. x
0.0039 in.
0.084 mm x
0.099 mm
600 dots/in. 0.0016 in. x
0.0016 in.
0.042 mm x
0.042 mm
N/A N/A
First dot location measured from
inside media backing edge
0.10 in. ±
0.04 in.
(2.5 mm ±
1 mm)
0.10 in. ±
0.04 in.
(2.5 mm ±
1mm)
Maximum print
width
203 dots/in. 4.09 in. 104 mm 6.6 in. 168 mm
Minimum print length 1 dot row 1 dot row
Maximum
continuous print
length
203 dots/in. 157 in. 3988 mm 102 in. 2590 mm
300 dots/in. 73 in. 1854 mm 45 in. 1143 mm
600 dots/in. 20 in. 508 mm N/A N/A
Bar code
modulus
(X) dimension
Picket fence
(non-rotated) orientation
203 dots/in. 4.9 mil to 49 mil 4.9 mil to 49 mil
300 dots/in. 3.3 mil to 33 mil 3.3 mil to 33 mil
600 dots/in. 1.6 mil to 16 mil N/A
Ladder
(rotated) orientation
203 dots/in. 4.9 mil to 49 mil 4.9 mil to 49 mil
300 dots/in. 3.9 mil to 39 mil 3.3 mil to 33 mil
600 dots/in. 1.6 mil to 16 mil N/A

Zebra Z Series Specifications

General

Print Method	Thermal Transfer or Direct Thermal
Max Print Width	4.09 in./104 mm (depending on model)
Max Print Length	39 in./991 mm (with 203 dpi)
Connectivity	USB, Serial (depending on model)
Supported Media Types	Wristbands
Media Width	1.0 inch (25.4 mm)
Operating Temperature	40°F to 104°F (5°C to 40°C)
Storage Temperature	-40° F/-40° C to 140° F/60° C
Resolution	203 dpi or 300 dpi (depending on model)
