29
Printer Setup
Select a Data Communication Interface
6/6/08 Z Series
®
/RZ™ Series User Guide 79695L-002 Rev. A
Table 6 • Connecting the Printer to a Computer or Network
Interface Connection and Configuration
RS-232 Serial The baud rate, number of data and stop bits, the parity, and the
XON/XOFF or DTR control must match those of the host computer. See
Standard Control Panel Parameters on page 69 to view or change these
parameters.
IEEE 1284
Bidirectional
Parallel
No additional configuration is necessary.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra Z Series and is the answer not in the manual?

Zebra Z Series Specifications

General IconGeneral
Print MethodThermal Transfer or Direct Thermal
Max Print Width4.09 in./104 mm (depending on model)
Max Print Length39 in./991 mm (with 203 dpi)
ConnectivityUSB, Serial (depending on model)
Supported Media TypesWristbands
Media Width1.0 inch (25.4 mm)
Operating Temperature40°F to 104°F (5°C to 40°C)
Storage Temperature-40° F/-40° C to 140° F/60° C
Resolution203 dpi or 300 dpi (depending on model)
