DESCRIPTION
Stemi DV4 / DR Compact version with stand C Carl Zeiss
B 40-003 e 08/00 2-5
Optical Data
Stemi DV4 and Stemi DV 4 SPOT
Eyepiece W 10x/20 Br. foc.
Attachment systems 0.3x 0.4x O.3x...0.5x 0.63x without 1.25x 1.6x 2x
FWD in mm 285 210 245...85 130 92 60 48 29
Magnification 2.4x...9.6x 3.2x...12.8x 2.4x...16.0x 5.0x...20.2x 8.0x...32.0x 10.0x...40.0x 12.8x...51.2x 16.0x...64.0x
Object field in mm 83.3...20.8 62.5..15.6 83.3...12.5 40.0...9.9 25.0...6.3 20.0...5.0 15.6...3.9 12.5...3.1
Stemi DR 1040
Eyepiece W 10x/20 Br. foc.
Attachment systems 0.3x 0.4x O.3x...0.5x 0.63x without 1.25x 1.6x 2x
FWD in mm 285 210 245...85 130 92 60 48 29
Magnification 3.0x/12.0x 4.0x/16.0x 3.0x...5.0x /
12.0x...20.0x
6.3x/25.2x 10.0x/40.0x 12.5x/50.0x 16.0x/64.0x 20.0x/80.0x
Object field in mm 66.7/16.7 50.0/12.5 66.7...40.0 /
16.7...10.0
31.8/7.9 20.0/5.0 16.0/4.0 12.5/3.1 10.0/2.5
Stemi DR 1663
Eyepiece W 10x/20 Br. foc.
Attachment systems 0.3x 0.4x O.3x...0.5x 0.63x without 1.25x 1.6x 2x
FWD in mm 285 210 245...85 130 92 60 48 29
Magnification 4.8x/18.9x 6.4x/25.2x 4.8x...8.0x /
18.9x...31.5x
10.1x/39.7x 16.0x/63.0x 20.0x/78.8x 25.6x/100.8x 32.0x/126.0x
Object field in mm 41.7/10.6 31.3/7.9 41.7...25.0 /
10.6...6.3
19.8/5.0 12.5/3.2 10.0/2.5 7.8/2.0 6.3/1.6
Illumination
Stemi DV4 / DR
Halogen – integrated reflected-light illuminator .....................................................................12 V, 20 W
Halogen – integrated transmitted-light illuminator..................................................................12 V, 10 W
Stemi DV4 SPOT
Near-axis, inclined reflected-light illumination...............via light guide and Schott KL200 cold-light source
...................................................................................................................................(5.5° illumination)
Plug-in power unit
Protection class .................................................................................................................................... II
