FLX & ZerOS Server
FLX S24 & FLX S48
FLX & ZerOS Server
Mains Inlet
FLX & ZerOS Server are fitted with a Neutrik PowerCON TRUE1 (NAC3MPX) mains inlet on the back panel, and
power on/off switch.
The internal fuse is not user replaceable, contact an authorized service agent if the desk does not power up and you
suspect that the fuse has failed. When using a UK style plug (BS 1363), a 5A fuse should be fitted.
100 - 240V AC; MAX 1A 50 - 60Hz, 60W INTERNALLY FUSED. A GOOD EARTH CONNECTION IS ESSENTIAL.
USB ports
Five external USB ports are fitted on the FLX. Two located on the rear of the console, one on the front panel, and one
on either side. Three external USB ports are fitted to ZerOS Server. Two located on the rear of the server and one on
the front. These support the USB 2.0 standard, and are “overload protected” in pairs. If a USB device tries drawing too
much power, ZerOS will disable that pair or ports until the device is unplugged.
USB ports can be used for:
Wings
Keyboard & Mouse
External Touchscreen (DVI-D also required)
External Storage Devices (such as Memory Sticks)
USB Desk Lights
Cooper Lighting Solutions UK Ltd cannot be responsible for damage caused to FLX by plugging in devices which
break the Universal Serial Bus standard.
Ethernet
FLX & ZerOS Server is fitted with a Neutrik etherCON RJ45 Ethernet port and is capable of supporting various
Ethernet protocols.
Zero 88 - ZerOS - Page 221 of 233 Printed: 23/11/2020 12:50:03 JH
