Zip HydroTap G5 BCS - Section 3.5 Lime Scale Filter Installation

806834 v1.02 07.21 G5 Online install instructions and user guide
23
SAFETY
INSTALLATION
TROUBLE SHOOTING
COMMISSION
USER GUIDE
TAP SAFETY
LCD SCREEN
CONTACT
INSTALLATION
GUIDE
An external lime scale filter may be fitted as an optional accessory to reduce the incidence of lime scale build
up in the hot tank or may be supplied at the customer’s request.
BC Comm
Water
in
Bypass out
Water
out
Bypass in
Insert
Remove
Insert
Remove
For filter head and lime scale
filter installation use the guide
supplied with the filter head and
filter respectively.
Bypass valve
(Rear of the Command
Centre)
Section 3.5 Lime scale filter installation
3.5.1 Lime scale filter
