INSTALLATION
GUIDE
Water supply pressure requirements
UK models: A pressure limiting valve must be fitted for mains water pressures above the
maximum limits stated above, in accordance with local plumbing regulations.
All other models (except UK): HydroTaps have an internal pressure limiting device to reduce
the maximum mains regulated pressure, protecting the system against pressure surges above
500 kPa.
Component
Min - Max pressure, kPa (bar)
Australia UK
HydroTap 170 (1.7) - 700 (7.0) 170 (1.7) - 500 (5.0)
Sparkling HydroTap 250 (2.5) - 700 (7.0) 250 (2.5) - 500 (5.0)
Vented Mixer Tap 300 (3.0 ) - 700 (7.0) 200 (2.0 ) - 500 (5.0)
Booster 200 (2.0) - 700 (7.0) 200 (2.0) - 500 (5.0)
Lime scale filter 200 (2.0) - 700 (7.0) 200 (2.0) - 500 (5.0)
Water supply connection
1/2” BSP (G1/2)
Electricity supply requirements
220-240V 50Hz AC (for power requirement see table above).
220 60Hz AC.
Booster specification
Specification Rating
Power 230V 50/60Hz 2.20 kW
Power 240V 50/60Hz 2.40 kW
Flow rate 1.2 L/m
Technical data
Country Without Booster With Booster
Australia 1x 220 - 240V AC 10A socket 2x 220 - 240V AC 10A sockets
UK 1x 220 - 240V AC 13A socket 2x 220 - 240V AC 13A sockets
