ZKTeco EC16 User Manual

EC16 Elevator Control Panel & DEX16 Elevator Floor Extension Board User Manual
P a g e | 11 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
No.
Description
No.
Description
1
Floor Button Control Port
16
Power Input
2
Extend Port
17
Ethernet Interface (LAN1)
3
Wiegand
18
TCP/IP Reader Interface (LAN2)
4
RS-485
19
U disk interface
5
LED Indicator
20
Reset Button
6
Elevator Door Closing Button
21
Floor Button Control Port
7
Elevator Door Opening Button
22
DIP Switch
8
Alarm Output
23
RS-485 Input
9
Speaker
24
RS-485 Output
10
Voice
25
Touch Keypad & RFID Card Reading Area
11
LED Indicator Port
26
Flash
12
Tamper Switch
27
QR Code Collector
13
FIRE
28
USB Jack
14
Emergency Button
29
RFID Card Reading Area
15
Manual Button
30
LED Indicator
Technical Parameters
EC16 Elevator Controller
Controllable Floors
16 floors
Record Capacity
150,000
User Capacity
30,000
Power Supply
Adopt Package C enclosure
matching adapter
Face Capacity
30,000
PC Communication
TCP/IP
Card Capacity
30,000
Reader Communication
Wiegand, RS-485
Fingerprint
Capacity
30,000
Number of connectable
expansion boards
Up to 7 DEX16s can be
connected at the same time
Block list Capacity
500
Number of expandable
floors
Up to 128 floors
DEX16 Expansion Board
Controllable Floors
16 floors
Communication With
EC16
Wiegand, RS-485
Power Supply
12V DC, powered
by EC16
