Appendix 1 Buzzer, Indicator Light Prompt Instructions
EC16 elevator controller works normally online, when the user verifies the RFID card in RS-485 reader
and Wiegand reader, the buzzer and indicator prompts are shown in the following table.
Working Status
Buzzer
Indicator Light
Verification Success
1 short sound
LED indicator lights green.
Verification Failure
(swipe unregistered card)
2 short sound
LED indicator (red) lights up
briefly twice.
Validation method error
2 short sound 1 long
sound
LED indicator (red) lights up
twice short and then once long.
Data transfer error
(Wiegand format error)
1 short sound 1 long
sound
LED indicator (red) lights up
one short and then once long.
No permission (person has expired, the
operation interval is too short, door is
not valid time period verification open,
illegal time period, illegal access, wrong
verification method, block list)
3 short sound
LED indicator (red) lights up
briefly three times.
Continue validation during combination
validation
/
Flashing green light three
times.
Combined verification is not completed
4 short sound (timeout
time of 10s)
LED indicator (red) lights up
briefly four times.
Timeout
4 short sound (timeout
time of 8s)
LED indicator (red) lights up
briefly four times.
