TCP/IP Communication
The Ethernet 10/100Base-T Crossover Cable, a type of crossover network cable, is mainly used for
cascade hubs and switches, or used to connect two Ethernet end-points directly without a hub. Both
10Base-T and 100Base-T are supterminaled.
Figure 6-1
Diagram of TCP/IP communication
1. In ZKBio CVSecurity software, click [Elevator] > [Elevator Device] >[Device] to enter the setting
interface.
2. Click [
Search
] to open the Search interface in the software.
3. After the search is completed, a list of controllers will be displayed. Select the controller in the list
and click [
Add
] behind the action bar.
4. In the Add window, enter the relevant parameters for the controller.
5. Click [OK] to save and exit.
